F23 Series Electric Hoist Wireless Remote Controller

Prod Model:	F23 series
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Product Name:	F23 Series Electric Hoist Wireless Remote Controll
Control Distance:	up to 100m
Control Motions:	8/10
Working Temperature:	-35 Deg C ~ +80 Deg C
Enclosure Protection Class:	IP 65
Transmitter:	DC 3V
Receiver Power:	AC 380V/220V/110V/48V/36V/24V or AC/DC 12V
Application:	Industrial Machinery
Signal Transmission:	Radio Waves
Type:	Button
Certification:	CE
Universal:	Universal
Transmission Distance:	50-100m
Battery Type:	AA Battery
Voltage:	Optional
Material:	Glass Fiber-Reinforced Nylon-6

Product Description

F23 Series electric hoist wireless remote controller

® F23 series only have two type F23-A++, F23-BB. A++ only have 8 control motions, and the 3, 4 is usless. BB have 10 control motions ®


Description of hoist wireless remote controller:

1. More than 10 years researching and exporting experience in Radio Remote Control industry.
2. Well and high quality control, all working process according to ISO9001:2008.
3. CE, FCC & ISO certificates.
4. One year warranty.
5. Sample order acceptable.
6. OEM acceptable.

Specification of F23 Series electric hoist wireless remote controller:


Control distance	Up to 100m
Unique code	Over 4.3 billion unique ID codes
Temperature	-35°C---+80°C
Enclosure protection class	IP65
Transmitter power	DC 3V
Receiver power	AC 380v/ 36v/220V or DC12V/24V
Output capacity	Full sealed relay output with 5 amperes (using ac 250v/10A relay, 5 amp fuse) .

Features of F23 Series electric hoist wireless remote controller:

* 10 single speed push button (F23-A++ 3,4 key are useless)
* control points are up to 8
*With the battery voltage alarm device to cut off the circuit when voltage is insufficient.
*with the Rotate key switch to guarantee the safety.
*set the internal functions by computer interface
*up/down ,east/west , south/ north push button can be set mutual inhibition or not .
*power button can be set start,speed up,jump strokes, ordinary etc.
*spare 1-2 key can be set ordinary, interlock,jump strokes,switch etc.


 Standard Configuration of F23 Series electric hoist wireless remote controller:

     One transmitter ;
     One receiver;
     One 1m cable connect with receiver
     One operation and maintain manual.


Application of F23 Series electric hoist wireless remote controller:

single hook electric cable hoist ,monorails,single speed electric hoist or electric single speed hoist crane, and used for the industrial remote control which are under 6 connection.
