Factory Price 60W Laser Power Supply for CO2 Laser Machine

Prod Model:	laser power supply
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Output Type:	Multiple
Warranty:	1 Year
Output Power:	51 - 100W
Input Voltage:	220V
Connection Mode:	Series Switching Power Supply
Starting Mode:	Self-excited Switching Power Supply
Voltage Regulating Mode:	Frequency Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	ISO
Brand:	Perfectlaser

Product Description

laser power supply for co2 laser machine
The laser power supply incorporates a zero-current half-bridge soft-switching circuit, ensuring high efficiency and fast response, easily compatible with various laser tubes from different manufacturers. The laser power supply is well worth buying because: the ports can be easily controlled to adapt to high and low level signals; the switch can be controlled by TTL electrical level; and the abnormal protection switch can test external water supply, ventilation, etc. And it is often used as industrial laser power supply, laser cutting machine power supply, laser engraving machine power supply, etc.

Features
1. Top quality: the materials are strictly selected (the major parts are imported); the 30W-150W laser power supply has passed multiple standard tests, low-temperature test, full-load and high-temperature tests, etc.
2. Great compatibility: the laser power supply is compatible with various sealed-off CO2 laser tubes from different manufacturers.
3. Fast response speed: the excellent speed attributes to great engraving and cutting performance and significantly extends the laser's service life.
4. Simple and easy control: it can be controlled to adapt to high and low level signals or switched on/off by TTL electrical level; laser power can be easily controlled by 0-5 V analog signal or PWM (pulse width modulation) signal.
5. Useful safety functions: the abnormal protection switch can test external water supply, ventilation, etc; in the well-grounding circumstance, the CO2 laser power supply can work under open circuit state within a short time to avoid damages caused by laser tube burst.
6. Premium special functions: there is no need to unpack the power cover to tell whether it is working in proper operation, so it is easy to locate where the problem is when it occurs.
7. Wide applications: the power supply is ideal for engraving and cutting on artwork and craft, PMMA, leather, cloth, rubber and other materials.

Technical Parameters of Laser Power Supply

AC input voltage	AC220V or AC110V
DC input voltage	DC300V or DC150V
AC input frequency	47-440Hz
Maximum output voltage	50KV
Maximum current	20mA-38mA (depending on different laser tubes)
Power supply efficiency	91%
Over current protection	130% of maximum current
Open circuit protection	Yes (short term)
Structure	Fan cooling
High electric level control voltage range	≥3V
Low electric level control voltage range	≤0.8V
Operating temperature	-30°C to +65°C
Relative humidity	20-85% RH (no condensation)
Voltage resistance	AC1500V1 minutes≤10mA
	AC1500V1 minutes ≤10mA
	Connection
Insulation resistance	≥50MΩ (DC500V)
Earth leakage current	≤1mA (AC220V) ≤0.5mA (AC110V)
Vibration resistance	Amplitude: 0.5mm frequency 10-55hz 3d direction 2 hours
MTBF	≥30,000hours
Test time at full load and 60°C	12 hours
Power supply switch test within 7 seconds	500 times
Output power	30W-150W

Pre-Sales Service
Whether you are a dealer or an end user, as long as you are interested in our laser machines and related products, once you contact us, we will arrange a particular professional at your service to help you have a deep understanding of EASTERN LASER and our products or answer your questions on laser products and laser applications. In order to keep open and convenient communication with you, EASTERN LASER integrates sales and service as one and the same responsible person is in charge of your sales and service.

On-Time Delivery
After you confirm the order, we will figure out the delivery date according to the model and production schedule. For general models, we will arrange production in 7 days or so and we will notify you of the exact phase of production process.

Production Process:
Machine Case---Mechanical Parts Installation---Electrical Parts Installation---Machine Commissioning--- Aging Test for at Least 24 Hours --- Nameplate, Logo and Packaging---Shipping

After-Sales Service
We guarantee all of our laser machines have a one-year warranty (quick-wear parts not included).
Numerous feedbacks from our clients have proven that our laser machines are stable in performance with rare malfunction. However, we would like to handle it as follows once malfunction occurs:
1.We guarantee we will give you a clear reply within 24 hours.
2. Customer service staff will assist and guide you to analyze the malfunction in order to locate the cause.
3. If the malfunction is caused by improper operation on software and other soft faults, we will help solve the problem on line.
4. If it is proved that a certain part is damaged, we will deliver a replacement part to you as soon as possible, so you can replace it by yourself, reducing unnecessary time cost.

Note
It is a usual practice for other manufacturers that they will not deliver the replacement parts until you return the damaged ones. However, we can ship replacement parts to you first. As for the core parts like main board, laser power supply, etc. you can return the damaged ones after the machine comes back to normal. As for small parts like belt, pulley, timing pulley, etc., you are not required to return the damaged ones so as to save the delivery fee.
EASTERN LASER, always at your service!
