| Prod Model: |
YJLV VLV BL36 |
| Application: |
Underground |
| Current: |
AC Cable |
| Insulation Material: |
PVC |
| Certification: |
CE |
| Voltage: |
0.6/1kv |
| Wire Core Material: |
Aluminum |
| Model: |
Nyy |
| Brand: |
Yifang |
Product Description
Factory Price Aluminum Core NYY Power Cable 0.6/1kV
Cable Application
NYY is used as a power cable for energy supply in static installations, indoors, outdoors, underground, in concrete and in water where mechanical damages are not to be expected. The use of NYY cables is in accordance with VDE 0298 part 1. The current capacity is according to HD 603 S.1 and VDE 0276 part 1000. The product conforms to EEC directive 73/23 (Low Voltage Directive). CE.
Technical Information
| Conductor: | Plain copper to IEC 60228 class 1 or 2 |
| Insulation: | PVC |
| Bedding: | PVC |
| Sheath: | PVC sheath, black |
| Cores: | Colour coded to VDE0293 |
| Voltage Rating: | 0.6/1kV |
| Bending Radius for Single Core: | Minimum: | 15 x Ø |
| Bending Radius for Multi Core: | Minimum: | 12 x Ø |
| O = no earth | |
| J = green/yellow earth | |
| Number of cores and mm2 per conductor | Approximate outside
in mm ca. | Copper weight
kg/km | Approximate weight
kg/km ca. |
NYY-J Voltage Rating 0.6 / 1kV |
| 1 x 25 rm | 13 | 240.0 | 360 |
| 1 x 35 rm | 14 | 336.0 | 470 |
| 1 x 50 rm | 15 | 480.0 | 640 |
| 1 x 70 rm | 17 | 672.0 | 850 |
| 3 x 1.5 re | 12 | 43.0 | 200 |
| 3 x 2.5 re | 13 | 72.0 | 260 |
| 3 x 4 re | 15 | 115.0 | 330 |
| 3 x 6 re | 16 | 173.0 | 430 |
| 3 x 10 re | 18 | 288.0 | 590 |
| 3 x 16 re | 20 | 461.0 | 810 |
| 3 x 25 rm /16 re | 26 | 874.0 | 1,520 |
| 3 x 35 sm/16 re | 28 | 1,162.0 | 1,800 |
| 3 x 50 sm/25 rm | 31 | 1,680.0 | 2,500 |
| 3 x 70 sm/35 sm | 35 | 3,252.0 | 3,300 |
| 3 x 95 sm/50 sm | 40 | 3,216.0 | 4,400 |
| 3 x 120 sm/70 sm | 43 | 4,128.0 | 5,400 |
| 3 x 150 sm/70 sm | 48 | 4,992.0 | 6,700 |
| 3 x 185 sm/95 sm | 52 | 6,240.0 | 8,000 |
| 3 x 240 sm/120 sm | 59 | 8,064.0 | 10,400 |
| 3 x 300/150 sm | 65 | 10,080.0 | 13,000 |
| 4 x 1.5 re | 13 | 58.0 | 230 |
| 4 x 2.5 re | 14 | 96.0 | 300 |
| 4 x 4 re | 16 | 154.0 | 400 |
| 4 x 6 re | 17 | 230.0 | 510 |
| 4 x 10 re | 19 | 384.0 | 720 |
| 4 x 16 re | 22 | 614.0 | 1,050 |
| 4 x 25 rm | 28 | 960.0 | 1,650 |
| 4 x 35 sm | 28 | 1,344.0 | 2,000 |
| 4 x 50 sm | 31 | 1,920.0 | 2,700 |
| 4 x 70 sm | 35 | 2,688.0 | 3,600 |
| 4 x 95 sm | 40 | 3,648.0 | 4,800 |
| 4 x 120 sm | 43 | 4,608.0 | 5,900 |
| 4 x 150 sm | 48 | 5,760.0 | 7,300 |
| 4 x 185 sm | 53 | 7,104.0 | 9,000 |
| 4 x 240 sm | 60 | 9216.0 | 11,400 |
| 5 x 1.5 re | 14 | 72.0 | 270 |
| 5 x 2.5 re | 15 | 120.0 | 350 |
| 5 x 4 re | 17 | 192.0 | 480 |
| 5 x 6 re | 19 | 288.0 | 610 |
| 5 x 10 re | 21 | 480.0 | 880 |
| 5 x 16 re | 24 | 768.0 | 1,250 |
| 7 x 1.5 re | 15 | 101.0 | 300 |
| 10 x 1.5 re | 17 | 144.0 | 420 |
| 12 x 1.5 re | 18 | 173.0 | 460 |
| 14 x 1.5 re | 19 | 202.0 | 520 |
| 16 x 1.5 re | 20 | 230.0 | 570 |
| 19 x 1.5 re | 21 | 274.0 | 600 |
| 21 x 1.5 re | 22 | 302.0 | 650 |
| 24 x 1.5 re | 23 | 346.0 | 750 |
| 30 x 1.5 re | 25 | 432.0 | 800 |
| 40 x 1.5 re | 28 | 576.0 | 1,050 |
| 52 x 1.5 re | 31 | 749.0 | 1,450 |
| 61 x 1.5 re | 33 | 878.0 | 1,680 |
| 7 x 2.5 re | 16 | 168.0 | 420 |
| 10 x 2.5 re | 19 | 240.0 | 600 |
| 12 x 2.5 re | 21 | 288.0 | 630 |
| 14 2.5 re | 22 | 336.0 | 740 |
| 16 x 2.5 re | 23 | 384.0 | 810 |
| 19 x 2.5 re | 24 | 456.0 | 850 |
| 21 x 2.5 re | 25 | 504.0 | 950 |
| 24 x 2.5 re | 27 | 576.0 | 1,100 |
| 30 x 2.5 re | 29 | 720.0 | 1,300 |
| 40 x 2.5 re | 32 | 960.0 | 1,700 |
| 52 x 2.5 re | 36 | 1,248.0 | 2,200 |
NYY-0 |
| 1 x 6 re | 9 | 58.0 | 140 |
| 1 x 10 re | 10 | 96.0 | 190 |
| 1 x 16 re | 11 | 154.0 | 240 |
| 1 x 25 rm | 13 | 240.0 | 360 |
| 1 x 35 rm | 14 | 336.0 | 470 |
| 1 x 50 rm | 15 | 480.0 | 640 |
| 1 x 70 rm | 17 | 672.0 | 850 |
| 1 x 95 rm | 19 | 912.0 | 1,120 |
| 1 x 120 rm | 21 | 1,152.0 | 1,370 |
| 1 x 150 rm | 23 | 1,440.0 | 1,700 |
| 1 x 185 rm | 25 | 1,776.0 | 2,100 |
| 1 x 240 rm | 28 | 2,304.0 | 2,700 |
| 1 x 300 rm | 30 | 2,880.0 | 3,200 |
| 1 x 500 rm | 39 | 4,800.0 | 5,400 |
| 2 x 1.5 re | 11 | 29.0 | 170 |
| 2 x 2.5 re | 12 | 48.0 | 220 |
| 2 x 4 re | 14 | 77.0 | 290 |
| 2 x 6 re | 15 | 115.0 | 360 |
| 2 x 10 re | 17 | 192.0 | 480 |
| 2 x 16 re | 19 | 307.0 | 660 |
| 3 x 15 re | 12 | 43.0 | 200 |
| 3 x 2.5 re | 13 | 72.0 | 260 |
| 3 x 4 re | 15 | 115.0 | 330 |
| 3 x 6 re | 16 | 173.0 | 430 |
| 3 x 10 re | 18 | 288.0 | 590 |
| 3 x 16 re | 20 | 461.0 | 810 |
| 4 x 1.5 re | 13 | 58.0 | 230 |
| 4 x 2.5 re | 14 | 96.0 | 300 |
| 4 x 4 re | 16 | 154.0 | 400 |
| 4 x 6 re | 17 | 230.0 | 510 |
| 4 x 10 re | 19 | 384.0 | 720 |
| 4 x 16 re | 22 | 614.0 | 1,050 |
| 4 x 25 rm | 28 | 960.0 | 1,650 |
| 4 x 35 sm | 28 | 1,344.0 | 2,000 |
| 4 x 50 sm | 31 | 1,920.0 | 2,700 |
| 4 x 70 sm | 35 | 2,688.0 | 3,600 |
| 4 x 95 sm | 40 | 3,648.0 | 4,800 |
| 5 x 1.5 re | 14 | 72.0 | 270 |
| 5 x 2.5 re | 15 | 120.0 | 350 |
re = round conductor, single wire rm = round conductor, multi wire sm = sectorial conductor
Also available in low smoke halogen free versions.
Certificates:
Zhengzhou Yifang Cable Co., Ltd is a large joint-stock\hi-tech enterprise established in 1988. We are specialized in wires & cables, including designment, production and sales.
There are more than 500 staffs in our factory including over 50 technical personnel, 5 senior engineers. With complete advanced cable producing equipments over 150 sets, complete testing equipments, a national level fire-resistant & flame retardant cable laboratory. Our technology has reached advanced levels at home and abroad.
Our main products include: Power Cable for voltage up to 220KV, Overhead insulated cable, ABC Cable, Building Cable and flexible cord, Control Cable, Rubber Cable, Bare Conductor(ACSR, AAC, AAAC, BCC), Welding Cable, Galvanized Steel Wire(Stay wire), flame retardant mining cable, etc
We have own IM/EX right, our products have been exported to Europe, Australian, Middle-east, South-east Asia, Africa, American, South American etc., being subjected to consistent good opinion of customers.
