Factory Price Wholesale China Mc4 Ybranch Connector High Quality Used for Solar Power Station

Name: Factory Price Wholesale China Mc4 Ybranch Connector High Quality Used for Solar Power Station
Brand: all-electronics-online.com
SKU: 725184582
Availability: InStock
Rating: 5 (124 reviews)

Price:	US $ 3-7.8/Pairs
Min Order:	1/Pairs
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	FMC4Y
Model No.:	Fmc4y
Rated Current:	30A
Rated Voltage:	1000VDC
Test Voltage:	6000V(50Hz, 1min)
Degree Of Protection:	IP2X/IP67
Contact Material:	Copper,Tin-Plated
Insulation Material:	PPO
Warranty:	5 Years
Connector:	Wirie Connector
Conductor Size:	2.5-6.0mm2
Type:	Socket Terminals
Application:	Solar Power System
Material:	Copper/Tin-Plated
Certification:	Ce CCC
Brand:	Feeo

Product Description

Factory Price Wholesale China MC4 Ybranch connector high quality used for solar power station

Product Description
MC4 y branch Features:
1. Simple assembly, easy to use
2. Suitable for different sizes of PV cable
3. Waterproof grade: IP67
4. Housing made of PPO material, anti-UV
5. High current carrying capacity
6. Contact material: Copper Tin Plated
7. High heat resistance, wear-resisting
MC4 y branch Parameters:

Technical Data
Brand	FEEO
Type	MC4 Y branch
Rated current	30A
Rated voltage	1000v DC
Test voltage	6000V(50Hz, 1min)
Overvoltage type/pollution degree	CAT III /2
Contact resistance of plug connector	0.5mΩ
Contact material	Copper, Tin-plated
Insulation material	PPO
Degree of protection	IP2X/IP67
Flame class	UL94-VO
Safety class	II
Suitable cable	2.5mm², 4mm², 6mm²
Insertion force/withdrawal force	≤50N/≥50N
Connecting system	Crimp connection
Temperature range	-40ºC ~ +110ºC

Detailed Images

Packaging & Shipping
MC4 y branch Package:
Standard export carton packing:
MC4 Y branch 100pair/ctn
Carton Size 44*34.5*35CM3
G.W./N.W.: 14/13.5kgs

MC4 y branch Delivery Time:
3-15 days after confirming order,detail delivery date should be decided according to production season and order quantity.
MC4 y branch Shipping:
1. Shipment port:SHANGHAI/NINGBO
2. By Air or by Sea for batch goods,Airport/ Port receiving;
3. Customers specifying freight forwarders or negotiable shipping methods!
Company Information

YUEQING FEEO ELECTRIC CO.,LTD.

is one of the leading manufactures and exporters in the field of solar PV products withmanufacturing facilities in Mainland China. We are specialized of DC MCB, DC SPD, DC FUSE, DC ISOLATOR, MC4.

FAQ

Q: If I'm interested in your mc4 connector when I can receive your quotation and detail information after send the enquiry?

A:All your enquiry will be replied in 24hours.

Q:Your mc4 connector seems perfect but what's the difference between you and other suppliers?Because I find some cheaper price from others!

A: Our mc4 connector is IP67 degree and they are high quality customized.for solar system I think compare the quality first and then compare the price is the best way.

Q:Can I get a sample before the order because I really don't how is your mc4 connector quality?

A:Of course!We also think sample order is the best way to build the trust.

Q:How's the delivery?Because I really need them is urgently?

A:For sample order 3~7days will be no problem.And for regular order we promise in 15days.

Q:How's the warranty period for your mc4 connector?

A:We offer two year warranty for our customer.
