| Prod Model: |
CAT6 UTP/FTP/SFTP Data/Network/Lan Cable |
| Conductor: |
0.54mm-0.57mm |
| Insulation: |
1.02mm HDPE/PVC |
| Jacket: |
5.8mmpe,PVC |
| Fluke Test: |
90m-100m 100%Pass |
| Certificate: |
Ce/ETL/SGS/RoHS |
| Key Words: |
CAT6 |
| Application: |
LAN Cable |
| Conductor Material: |
BC/CCS/CCA/TC/CU/CCAG |
| Cover Material: |
PVC |
| Type: |
Cat 6 |
| Certification: |
CCC |
| Brand: |
Dongsheng Cable |
Product Description
1000ft 0.57mm 23AWG 4 Pairs utp cat6 cable
UTP Cat6 Networking Cable,Lan Cable Cat6 UTP
We can ensure the cable pass FLUKE TEST 100% for CU conductor, with a high
performance in your Cabling solution, or projec.
1. Certification: CE. RoHS,REACH,ISO Listed
2. Compliance: ETL verified ANSI TIA/EIA568-2, ISO/IEC 11801. RoHS Compliant.
3.Application: 100Base-TX, 100VG-AnyLan, 1000Base-T, ATM, Noisy Environment
4. Remark: 250HMZ 550MHz ATM 155MBPS, 100mbps TPDDI, Fast Ethernet etc
Specifications:
Cat6 Communication Cables,Cat6 Networking Cable,Lan Cable Construction:
Item | Conductor | Number Of Pairs | Shielding | Drain Wire | O.D. |
Cat6 UTP | 0.57mm BC/CCA | 4 | Non | Non | 6.2mmPVC ROHS,UV,LSZH,UL,Reach |
Cat6 FTP | 0.57mm BC/CCA | 4 | Aluminum Foil | Yes | 6.8mm PVC ROHS,UV,LSZH,UL,Reach |
Cat6 SFTP | 0.57mm BC/CCA | 4 | Aluminum Foil + Alloy Braiding | Yes | 7.2mm PVC ROHS,UV,LSZH,UL,Reach |
UTP Cat6 Outdoor | 0.57mm BC/CCA | 4 | Non | Non | PVC+PE PVC ROHS,UV,LSZH,UL,Reach |
FTP Cat6 Messenger | 0.57mm BC/CCA | 4 | Aluminum Foil | Yes | PVC+Messenger ROHS,UV,LSZH,UL,Reach |
Cat6 Networking Cable Technical Performance(100m)
Frequency MHz | Impedance ohm | RL ≥dB | Attenuation ≤dB/100m | NEXT ≥ dB/100m | ELFEXT ≥ dB/100m | PS NEXT ≥ dB/100m | PS ELFEXT ≥ dB/100m | NVP |
1 | 100±15 | 20.0 | 2.0 | 65.3 | 63.8 | 62.3 | 60.8 | 68% |
4 | 23.0 | 4.1 | 51.7 | 51.7 | 53.3 | 48.7 |
10 | 25.0 | 6.5 | 43.8 | 43.8 | 47.3 | 40.8 |
16 | 25.0 | 8.2 | 39.7 | 39.7 | 44.2 | 36.7 |
20 | 25.0 | 9.3 | 37.8 | 37.8 | 42.8 | 34.7 |
31.25 | 23.6 | 11.6 | 33.9 | 33.9 | 39.9 | 30.9 |
62.5 | 21.5 | 17.0 | 27.8 | 27.8 | 35.4 | 24.8 |
100 | 20.1 | 22.0 | 23.8 | 23.8 | 32.3 | 20.8 |
*155 | 100±18 | 18.8 | 28.1 | 20.0 | 20 | 29.4 | 17.0 |
*200 | 18.0 | 32.4 | 18 | 18.0 | 27.8 | 15.0 |
*310 | 100±22 | 16.7 | 41.8 | 14 | 14.0 | 24.9 | 11.0 |
*350 | 16.3 | 44.9 | 13 | 13.0 | 24.1 | 10.0 |
Cat6 Networking Cable Applications:
Cat6 Communication Cables
1.Computer Network Cabling Project.
2.Broadband Network Communication.
3.Digital ISDN Network and ATM 155Mbps Network
4.Ethernet Network
5.Audio and Data Transmission
Cat6 Communication Cable,Lan Cable,Network Cable Package
Factory Show
Products Certifications
Exhibition Trade Show
