Far Transmission Fiber Optical Patch Cord with Odva-LC Socket

Name: Far Transmission Fiber Optical Patch Cord with Odva-LC Socket
Brand: all-electronics-online.com
SKU: 691336041
Availability: InStock
Rating: 4.5 (49 reviews)

Price:	US $ 2-50/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	FA-ODVA-LPLAS2
Color Of Jacket:	Black or Customized
Length:	Customized
End Polishing:	PC, Upc
Cable Diameter:	7.0mm
Cable Length:	Customized
Jacket Material:	TPU or Customized
Fiber Type:	G652 or Customized
Waterproof Plug:	Odva
Use In:	Ftta, Far Transmission, Base Station
Protection Grade:	IP65
Application:	Probe
Type:	Single-mode Fiber
Certification:	ISO9001
Connection Structure:	Odva-LC
Sheath Material:	TPU

Product Description

FA-ODVA-LPLAS2, Far Transmission Fiber Optical Patch Cord With ODVA-LC Socket

Main Features Of ODVA-LC Fiber Patch Cord

1, With screwing locking mechanism, ensure the reliability for long-term connection;
2, The waterproof plug is water proof, dust proof and corrosion resistant;
3, Compact appearance, robust and flexible;
4, IP67 protection rate prevent the fiber connector from dust and water immersion;
5, LC fiber optic connector is qualified to Telcordia GR-326 and TIA/EIA 568B.3;
6, Both single mode and multimode versions are available;
7, Suitable wide temperature range from -40ºC to +70ºC.

Parameters Of FA-ODVA-LPLAS2 Patch Cord

Product type	ODVA-LC
Connector type	LC/LC
Fiber capacity	Duplex fiber
Jacket Material	TPU, LSZH, PVC, Armour or customized
Cable type	Far transmission cable, tactical fiber cable or indoor armoured optical cable and so on.
Cable length	Upon order
Insertion loss	IL<0.2dB
Return loss	RL SM/PC≥55db SM/APC≥65db MM/PC≥35db
Mating time	>1000 times
Working temperature	-40ºC to +70ºC
Cable diameter	OD7.0mm or customized
Protection grade	IP67
RoHS	Compliant

Shenzhen Fiberall Technology Co., Ltd was started in 2007 and we are located in Shenzhen China. As a company engaged in fiber optical engineering related products, our main business including: Research and development (R&D), manufacturing, marketing; Optical engineering solution design; Maintenance, consulting service and accessories outsourcing.

Our main products are: All kinds of Fiber PLC Splitters, FBT Couplers, Fiber Cable Assemblies, Patch Cords, Fiber Pigtails, Fiber Adapters, Patch Panels, Fiber Optical Transceivers, OLT (Optical Line Terminal), OUN (Optical Network Unit), FTTX, Equipments & Accessories for Fiber Test, Installation, Maintenance & Repair.

With eight years' experience in fiber optic, Fiberall established a relatively perfect products and service system, with rich industry experience, comprehensive technology and high-quality team, we are able to provide our customers with OEM & ODM service, project implementation, maintenance, and after-sale service and we have ability to meet different requirement from different customers like distributors, operators, contractors and users etc.
