Fast Recovery Rectifiers FR101

Name: Fast Recovery Rectifiers FR101
Brand: all-electronics-online.com
SKU: 730374382
Availability: InStock
Rating: 4.7 (143 reviews)

Price:	US $ 0.0015-0.095/Piece
Min Order:	500000/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	FR101

Product Description

Fast recovery rectifier diode belongs to the high frequency rectifier diode rectifier diode, is referred to as the fast recovery diode, this is because the general rectifier diode is generally work in low frequency (such as mains frequency 50 hz), its working frequency under 3 KHZ.
Fast recovery rectifier diode belongs to the high frequency rectifier diode rectifier diode, is referred to as the fast recovery diode, this is because the general rectifier diode is generally work in low frequency (such as mains frequency 50 hz), the working frequency is lower than 3 kHz, when work in a few to several hundred kHz frequency, voltage change direction, time to slow recovery time, ordinary rectifier diode can't normal to achieve single wizard, then with quick restore fast recovery rectifier diode.
The characteristics of fast recovery diode is its recovery time is short, this feature makes it suitable for high frequency (such as the TV line frequency) of the rectifier.Have a fast recovery diode determines the performance of the important parameters of reverse recovery time.Reverse recovery time is defined as sharp transition to the diode to the from state by state, since output pulse down to zero, to reverse the power back to the maximum 10% of the time required to reverse current, commonly used symbols TRR said.Ordinary fast recovery rectifier diode TRR Andrew bynum for a few seconds (10-9 s), super fast recovery diode TRR general for dozens of nanoseconds.The smaller the Trr fast recovery diode work frequency is higher.

Established in 2000, Changzhou Zhongguang Electronic Co., Ltd(ZG), which locates in Changzhou city, Jiangsu province, a place concentrated with China's most vigorous manufacturers, our company has a wide variety of products with complete specifications, including diodes, bridge rectifiers and automotive rectifier diodes, transient voltage suppressors(TVS), general rectifier(STD), fast recovery diode(FR), high efficiency rectifiers(HER/UF), super fast recovery diodes(SF) and schottky diodes(SKY). The main package includes A-405, DO-41, DO-15, R-1, R-6, DO-201AD. TO-220AB. TO-220AC, SMA, SMB, SMC, MBS, MBM, DBS, dB, WOB, RS-2, GBJ2, KBPC1, KBP, KBL, GBJ4, KBU, GBJ6, GBU, KBPC6, KBPC8 etc.

And the company untroduced a full set of advanced equipment and scientific management system from abroad. The quality of our products enjoys a good reputation in domestic and foreign markets. The company could supply competitive price and fast delivery and good quality with prompet service.

Our products are widely used in the fields like home appliances, LED, energy saving lamp, smart electric meters, security and protection, extinguishing and protection and automotive electronics etc.

We also work with DHL, FedEx, TNT and etc. For large quantity, it's up to you to choose the freight for warder and if you need, we could assist you.
