FC APC to FC APC Duplex Sm Fiber Patch Cable/Cord
| Price: |
US $ 0.1-10.00/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
DF-FCA-13 |
| Connector: |
FC to FC |
| Jacket Od: |
2.0mm |
| Fiber Mode: |
9/125μm |
| Jacket Color: |
Yellow |
| Polish: |
APC to APC |
| Wavelength: |
1310/1550nm |
| Fiber Type: |
Duplex |
| Jacket Material: |
PVC |
| Insertion Loss: |
≤0.3dB |
| Interchangeability: |
≤0.2dB |
| Application: |
Communication |
| Type: |
Single-mode Fiber |
| Connection Structure: |
FC |
| Certification: |
CE |
Product Description
FC APC to FC APC Duplex 2.0mm LSZH 9/125 Single Mode Fiber Patch CableCompliant with IEEE 802.3z standards for Fast Ethernet and Gigabit Ethernet applications
High Quality and Cost-effective 9/125μm Singlemode Fiber Patch Cable
The 9/125μm single mode fiber patch cable meets RoHS compliant, and all cables are 100% optically tested for insertion loss to ensure high quality, it is very cost-effective for network cabling. | Connector | FC to FC | Jacket OD | 2.0mm |
| Fiber Mode | 9/125μm | Jacket Color | Yellow |
| Polish | APC to APC | Wavelength | 1310/1550nm |
| Fiber Type | Duplex | Jacket Material | PVC |
| Insertion loss | ≤0.3dB | Interchangeability | ≤0.2dB |
| Return loss | ≥60dB | Vibration | ≤0.2dB |
| Operating temperature | -40~75°C | Storage temperature | -45~85°C |
| Polarity | A(Tx) to B(Rx) | Fiber Grade | G652D |
Product Highlights
Industry Standard Flammability Rating OFNR (Riser) Jacket Fiber Optic Cable
The industry standard duplex fiber connector meets EIA/TIA 604-2 with ceramic ferrule for high speed cabling networks.Zirconia Ceramic Ferrule Optimum IL and RL
Cable Boot, Provides Maximum Protection
Printing helps clarify and recognize different cables
Quality ControlAll products must go through five checks before manufacturing process
1.Material incoming inspection before production
2.Full check after every individual process finished
3.Full check after production half-done
4.Full check before packing
5.Spots check after production packed before shipping
Advantage1.15 years experience in manufacturing fiber optic products..
2.Availability of R & D with more than 10 engineers.
3.Available of design and making mold with special molding house.
4.High quality, attractive price and fast delivery(2-7days)
5.OEM, ODM customer designs are also welcomed
6.More than 200 workers
7.Excellent surviceContact1.Our working time:8:30am~5:30pm
2.All the inquiries will be replied within 24hours, So please feel free to send us your inquiry.
3.When our trade manager is off line, please feel free to leave a message, and tell us the products you need, our model number, and your E-mail address, we will reply to you within 24hours too.
Takfly Communications Co., Ltd. is a Hi-Tech enterprise having its own brand and specializing in R&D, manufacture and sales of fiber optical communications equipments.
The main products of TAKFLY include fiber optic patch cord, connector, adapter, optical coupler, attenuator, optic media converter, optic splice closure, optic terminal box, ODF etc, which are widely used in telecommunications, broadband, broadcast, CATV and network industry. All the products acquired the approval of the Network Access License for Telecommunication Equipment Ministry of Information Industry, PRC, ISO9001, UL and CE standard, which ensure the reliability and make them sold very well not only in the domestic market but also the overseas market.
TAKFLY was establish in 2000, grow up rapidly. Now it has workshop area about 3000 square meters, more than 200 workers, the production capacity of fiber optic connectors is about 600, 000PCS per month. It controls the quality constantly and strictly in order to give the best products to the users. The outstanding features and advantage are the high technology, professional and excellent sales team, efficient and sound management, competitive price, wide and superior channels, as well as high-quality and flexible service.
Many international exhibitions upgraded "TAKFLY" as the well-known brand in the world. To be the super leader of the optical communications scopes in China is the goal of TAKFLY. In the next five years, TAKFLY will keep the strategic pattern of development ---"based in South China, penetrate into whole country, extend over the world". It will bring the fiber optic industry into a brilliant future. TAKFLY--- Your Honest Team, will be always ready for you.
