Fcp Flexible Ceramic Heater Pad
| Price: |
Negotiable/Piece |
| Min Order: |
5/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
Product Description
FCP flexible ceramic heater pad
Flexible Ceramic Pad (FCP) Heaters are made from 95% Al2O3. These pad heaters are assembled of interlocking sintered alumina ceramic beads which insulate stranded nickel-chrome wire. This durable construction forms a flexible mat of remarkable mechanical strength.
Applications
FCP heaters are used as heating sources in furnaces and industrial process equipment operating at temperatures up to 1100°C. It is also used in post heat treatment of weld joints and preheating of materials to be welded. Heating Elements operate on low voltage (80 volts or less on AC or DC current) such as that supplied by a typical arc welding power source. These mats are basically used as flexible and mobile ovens.
Preheating treatment
Post-heating treatment
Heating of tubes
Heating of vessels
Heating of containers
Forms of Delivery
The mats are commonly made of 95% Al2O3. Their modular design permits a variety of element shapes, sizes, and thermal capacities to choose from.
Most common elements are as follows:
| Voltage (V) | 80 |
| Current (A) | 45 |
| Power (kw) | 2.7 |
| Maximum Use Temperature*, °C(°F) | 1100 (2050) |
| Heating Element Type | Ni-Cr 2080 |
| Lead Length (in.) | ~24 |
| Insulator Type | Aluminum Oxide |
| Insulator Color | Pink |
Ceramic Pad Heaters(60V)
60V Heaters| List Reference | Power Current | Description | Size Inches(approx) |
| CP3-60V | 2.7KW 45amp | Preheater | 3*29 |
| CP4-60V | 2.7KW 45amp | Preheater | 4*21 |
| CP6-60V | 2.7KW 45amp | Thick Wall Pad | 6*15 |
| CP8-60V | 2.7KW 45amp | Pad Element | 8*11 |
| CP10-60V | 2.7KW 45amp | Pad Element | 10*9 |
| CP12-60V | 2.7KW 45amp | 3"Diameter Pipe | 12.7 |
| CP15-60V | 2.7KW 45amp | 4"Diameter Pipe | 15*6 |
| CP18-60V | 2.7KW 45amp | Strip | 18*5 |
| CP21-60V | 2.7KW 45amp | 6"Diameter Pipe | 21*4 |
| CP26-60V | 2.7KW 45amp | Long Strip | 26*3 1/2 |
| CP50-60V | 2.7KW 45amp | Snake | 50*2 |
Specifications:Ceramic pad heaters are made of ceramic beads,nickel chrome wire 80/20 strand with cold tails(Nickel 212 wire)and make 60 amp twistlocks with insulated covers.Ceramic Pad Heaters(80V)80V Heaters
| List Reference | Power Current | Description | Size Inches(approx) |
| CP3-80V | 3.6KW 45amp | Preheater | 3*39 |
| CP4-80V | 3.6KW 45amp | Preheater | 4*29 |
| CP6-80V | 3.6KW 45amp | Thick Wall Pad | 6*20 |
| CP8-80V | 3.6KW 45amp | Pad Element | 8*15 |
| CP10-80V | 3.6KW 45amp | Pad Element | 10*12 |
| CP12-80V | 3.6KW 45amp | 3"Diameter Pipe | 12*10 |
| CP15-80V | 3.6KW 45amp | 4"Diameter Pipe | 15*8 |
| CP18-80V | 3.6KW 45amp | Strip | 18*7 |
| CP21-80V | 3.6KW 45amp | 6"Diameter Pipe | 21*6 |
| CP24-80V | 3.6KW 45amp | Strip | 24*5 |
| CP29-80V | 3.6KW 45amp | Strip | 29*4 |
| CP36-80V | 3.6KW 45amp | Long Strip | 26*31 1/2 |
| CP72-80V | 3.6KW 45amp | Snake | 72*2 |
Specifications:Ceramic pad heaters are made of ceramic beads,nickel chrome wire 80/20 strand with cold tails(Nickel 212 wire)and make 60 amp twistlocks with insulated covers.
Shenzhen superb heater technology Co., Ltd, Founded in 1985, Start is a state run Magnesium Oxide factory, After privatization reform To become a professional to provide all kinds of electric heating products of the comprehensive private joint-stock companies, After years of development company now grown to have include: ChaoHu heating material fitting, JiuDing machinery and spare parts, LiLin cartridge heaters, chaohu band coiling heaters, JXC Industrial heaters five plants, more than 200 employees, assets of more than $ 5 million, Products include various types of industrial heater, cartridge heater, hot runner, thermocouples, band heater and a variety of heater materials and heater equipment to meet customers one-stop shopping for all kinds of heating element, heating materials and heating equipment needs.
Over the years we are committed to technology and product quality improvement, many products similar products meet international quality, in China in the lead, swaged-in leads cartridge heater and diameter less 4mm cartridge heater as China's first single, cost-effective products to give our customers highly recognized, it has been to establish and maintain long-term cooperative relations with more than 700 customers in over 40 countries.
We will insist on our stable style to establish good image in both customers and our partners. We have been insisting on the "REDUCING THE COST AND GIVING ADVANGTAGE TO CUSTOMERS " To provide customers with better products and services, and grow with customers
After long-term accumulation, we have set up agents and partners in India, Dubai, USA, Russia, Brazil, Argentina, Thailand, Korea and other countries to provide convenient and quick service
