Product Description
FCP flexible ceramic heater padFlexible Ceramic Pad (FCP) Heaters are made from 95% Al2O3. These pad heaters are assembled of interlocking sintered alumina ceramic beads which insulate stranded nickel-chrome wire. This durable construction forms a flexible mat of remarkable mechanical strength.
ApplicationsFCP heaters are used as heating sources in furnaces and industrial process equipment operating at temperatures up to 1100°C. It is also used in post heat treatment of weld joints and preheating of materials to be welded. Heating Elements operate on low voltage (80 volts or less on AC or DC current) such as that supplied by a typical arc welding power source. These mats are basically used as flexible and mobile ovens.
Preheating treatment
Post-heating treatment
Heating of tubes
Heating of vessels
Heating of containers
Forms of DeliveryThe mats are commonly made of 95% Al2O3. Their modular design permits a variety of element shapes, sizes, and thermal capacities to choose from.
Most common elements are as follows:
Main Body Beads
Female End Beads
Male End Beads
Tail Beads
Main Body Beads with Holes
Characteristics & properties| Voltage (V) | 80 |
| Current (A) | 45 |
| Power (kw) | 2.7 |
| Maximum Use Temperature*, °C(°F) | 1100 (2050) |
| Heating Element Type | Ni-Cr 2080 |
| Lead Length (in.) | ~24 |
| Insulator Type | Aluminum Oxide |
| Insulator Color | Pink |
Ceramic Pad Heaters(60V)
60V Heaters| List Reference | Power | Current | Description | Size Inches(approx) |
| CP3-60V | 2.7KW | 45amp | Preheater | 3*29 |
| CP4-60V | 2.7KW | 45amp | Preheater | 4*21 |
| CP6-60V | 2.7KW | 45amp | Thick Wall Pad | 6*15 |
| CP8-60V | 2.7KW | 45amp | Pad Element | 8*11 |
| CP10-60V | 2.7KW | 45amp | Pad Element | 10*9 |
| CP12-60V | 2.7KW | 45amp | 3"Diameter Pipe | 12.7 |
| CP15-60V | 2.7KW | 45amp | 4"Diameter Pipe | 15*6 |
| CP18-60V | 2.7KW | 45amp | Strip | 18*5 |
| CP21-60V | 2.7KW | 45amp | 6"Diameter Pipe | 21*4 |
| CP26-60V | 2.7KW | 45amp | Long Strip | 26*3 1/2 |
| CP50-60V | 2.7KW | 45amp | Snake | 50*2 |
Specifications:Ceramic pad heaters are made of ceramic beads,nickel chrome wire 80/20 strand with cold tails(Nickel 212 wire)and make 60 amp twistlocks with insulated covers.
Ceramic Pad Heaters(80V)
80V Heaters| List Reference | Power | Current | Description | Size Inches(approx) |
| CP3-80V | 3.6KW | 45amp | Preheater | 3*39 |
| CP4-80V | 3.6KW | 45amp | Preheater | 4*29 |
| CP6-80V | 3.6KW | 45amp | Thick Wall Pad | 6*20 |
| CP8-80V | 3.6KW | 45amp | Pad Element | 8*15 |
| CP10-80V | 3.6KW | 45amp | Pad Element | 10*12 |
| CP12-80V | 3.6KW | 45amp | 3"Diameter Pipe | 12*10 |
| CP15-80V | 3.6KW | 45amp | 4"Diameter Pipe | 15*8 |
| CP18-80V | 3.6KW | 45amp | Strip | 18*7 |
| CP21-80V | 3.6KW | 45amp | 6"Diameter Pipe | 21*6 |
| CP24-80V | 3.6KW | 45amp | Strip | 24*5 |
| CP29-80V | 3.6KW | 45amp | Strip | 29*4 |
| CP36-80V | 3.6KW | 45amp | Long Strip | 26*31 1/2 |
| CP72-80V | 3.6KW | 45amp | Snake | 72*2 |
Specifications:Ceramic pad heaters are made of ceramic beads,nickel chrome wire 80/20 strand with cold tails(Nickel 212 wire)and make 60 amp twistlocks with insulated covers.
