| Prod Model: |
GS-LFD3015 |
| Power: |
1000 Watt |
| Drive: |
Double Drive |
| Control: |
CNC |
| Z Axle Stroke: |
150mm |
| Max. Cutting Speed: |
40m/Min |
| Max. Positioning Speed: |
80m/Min |
| Laser Wavelength: |
1070nm |
| Cooling: |
Water Cooling |
Product Description
Fiber Laser 1500W Metal Laser Cutting Machine Water CoolingPrecision and Wear Resistance Screw Drive System
1. Smooth rolling, small friction coefficient, no empty rollingeven in micro feeding, realize nanometer located accuracy.
2. The frictional resistance of rolling is small, and the structure is simple, low abrasion of friction contact surface, thus realize the long time walking accuracy.
3. Optimal design of geometric mechanics structure, steel balls of 45° array, could not only bear the power of warp, anti-warp and cross directions at the same time, but also assure the walking accuracy.
Products
Parameters of GS-LFD3015 laser cutter| Model | GS-LFD3015(Dual Drive) |
| Output power of laser source | 2000W |
| Cutting area (L*W) | 3000mm × 1500mm |
| Z axle stroke | 150 mm |
| Max. cutting speed | 40m/min |
| Max. positioning speed | 80m/min |
| Platform size/Max height of feeding material | 4250x2500mm/more than 120mm |
| Cooling | water cooling |
| Laser wavelength | 1070nm |
| Cutting gap | 0.1-0.3mm |
| Positioning accuracy of X, Y and Z axles | ±0.03 mm |
| Repeated positioning accuracy of X, Y and Z axles | ±0.02 mm |
Thickness of cutting material
(according to material) | 0.2-12mm |
| Drive model | Imported servo motor |
| Voltage | 380V,50/60Hz |
| Temperature | 5ºC-45ºC |
| Continuous working time | 24 Hours |
| Wok platform max bearing | 600Kgs |
| Complete System Coverage | 4500x2700mm |
| Total protection level of power supply | IP54 |
IPG Fiber Laser SourceWe adopts the world's highest level IPG fiber laser source, stable performance, assured safety of the whole product quality.
| Specifications of CF3015-2000 |
| Operation mode | CW,QCW |
| Center wavelength of radiation | 1070-1080 Nm |
| Standard output | 2000 W |
| Beam quality | 4 mm*mrad |
| Adjusting speed | 5 kHz |
| Fiber Diameter | ≥50 μm |
| Output stability(long-time) | ±2 % |
| Power | 400-460 VAC |
| power dissipation | 8 kW |
| Max. Power dissipation of cooling water | 0.4 M3/h |
| Size(W*D*H) | 850×800×1190mm |
| Weight | 350 Kg |
Excellent electronic control, comprehensive maintenance indicator1 Unique cooling design with in-built refrigeration type dryer.2 Up and down structure arrangement, mould structure design which is more compact3 Easy adjustment and less vibration Cutting Sample
About our companyHans Goldensky Laser System Co., Ltd. is one of the four manufacturing base of Han's Laser Technology Industry Group Co., Ltd.Hans Goldensky Laser System Co., Ltd is subsidiary company of Han's Laser Technology Industry Group Co., Ltd, (stock code: 002008). We are high-tech enterprise specialized in R&D, manufacture and sales for complete equipment of high-power laser source, laser cutting, laser welding, laser fusion covering, laser heat-processing and high-speed laser punching machine. We also provide automatic processing solving plans.
Wuhan Hans Goldensky Laser System Co., Ltd is subsidiary company of Han's Laser Technology Industry Group Co., Ltd, (stock code: 002008). We are high-tech enterprise specialized in R&D, manufacture and sales for complete equipment of high-power laser source, laser cutting, laser welding, laser fusion covering, laser heat-processing and high-speed laser punching machine. We also provide automatic processing solving plans.
Company has been successively undertaken the national development and reform commission (NDRC) national high-tech industrialization demonstration projects, the top ten key projects in Hubei province, Wuhan city top ten industrial projects of science and technology, and other government science and technology projects, including three products listed as a key project of national torch plan by the national ministry of science and technology. We successively obtains the national innovation fund, the electronic information industry development fund and a number of special fund support of Hubei province and Wuhan city, to be listed as the key innovation enterprise in east lake development zone, the key support leading enterprise in "large-scale laser equipment system integration and the new type laser manufacturing field" in Wuhan's 11th five-year plan.
Most of the products of our company has fully independent intellectual property rights, widely used in steel metallurgy, petroleum, tobacco, automobile, machinery, aerospace, chemical, home appliances and other manufacturing industries. In the future, the company will continue to be based on innovation of new and high technology, using its own technology advantages to contribute to the industrialization development of laser processing complete equipment.
