Fiber Optic Adapter Sc Sm Duplex with Flange

Name: Fiber Optic Adapter Sc Sm Duplex with Flange
Brand: all-electronics-online.com
SKU: 774515775
Availability: InStock
Rating: 4.8 (120 reviews)

Price:	US $ 0.9-1/Piece
Trade Terms:	FOB,EXW
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	SC adapter Single mode duplex with flange
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Certification:	ISO, RoHS
Color:	Green, Blue, Beige,Magenta
Mode:	Singlemode; Multimode, APC
Material:	Plastic
Sleeve:	Zr;Br
Dust Cap Type:	Shuter, Rubber
Other:	Simplex, Duplex
Flange:	Flangeless; with Flange
Transmission Medium:	Single-Mode
Structure:	SC
Ferrule Endface:	PC(',UPC)
Number Of Cores:	Duplex
Light Source TYPE:	Optic Fiber
Brand:	Koc

Product Description

High quality Fiber Optic SC Adapter Single Mode Duplex with Flange Blue Housing

Details:
An adapter is a mechanical device designed to align fiber-optic connectors. It contains the interconnect sleeve, that holds the two ferrules together.

Features:

Types: FC-LC, FC-SC, FC-ST, FC-MU, SC-ST

Low insertion loss, high return loss

Good compatibility

High precision of mechanical dimensions

High reliability & stability

Ceramic or Bronze Sleeve

PC,APC,UPC optional

Simplex / Duplex

APPLICATIONS
CATV
Active device/Transceiver
Telecommunication networks
Metro
Multimedia
Data processing networks
Test equipment
Premise installations
Gigabit Ethernet
Video

FEATURES
One piece solid body, no welding point
Low insertion loss and back reflection loss
Telcordia, ANSI, TIA/EIA, NTT and JIS compliance
High precision alignment
Compact design
Plastic housing

AVAILABILITY

With zirconia sleeve	With PB sleeve	Simplex
Duplex	Duplex with SC footprint	LC/APC

SPECIFICATIONS

Insertion Loss	<0.20dB
Durability	<0.20 dB typical change, 1000 matings
Operating Temperature	-40 to + 85°C

Equipment Test

Parameter	Unit	LC, SC, FC, MU, ST, SC-ST, FC-ST, FC-SC, FC-LC, FC-MU				MTRJ			E2000
		SM			MM	SM		MM	SM
		PC	UPC	APC	PC	PC	UPC	PC	PC	APC
Insertion Loss (Typical)	dB	≤0.3	≤0.2	≤0.3	≤0.2	≤0.3	≤0.2	≤0.2	≤0.3	≤0.3
Return Loss	dB	≥45	≥50	≥60	≥30	≥45	≥50	≥35	≥55	≥75
Exchangeability	dB	≤0.2				≤0.2			≤0.2
Repeatability	dB	≤0.2				≤0.2			≤0.2
Durability	Time	>1000				>1000			>1000
Operating Temperature	ºC	-40~75				-40~75			-40~75
Storage Temperature	ºC	-45~85				-45~85			-45~85

Shenzhen KOC Communication Co., Ltd. Is specialized in fiber optic communication product manufacture. Our products range from the basic components to end products, including passive and active categories as follows: Basic Components: Connector kits, Adapter kits, Attenuator kits.

Passive products: Connector, Adapter, Attenuator, Patch-cord, ODF and enclosure.

Active products: Media converter, Transmitting and receiving assemblies, such as laser diode assembly, PD and PIN/TIA assembly, sub-assemblies such as TOSA, ROSA, BOSA.

FTTH System: Gpon: OLT, ONU, PLC

Headquarter located in Shenzhen, China, we have branch companies, representatives and distributors in Europe, America, Middle East, South Asia. KOC products are well accepted and sold in these areas.

We provide all our products with high quality, competitive price, short delivery lead time and excellent after-sales services.

About KOC

Located in Shenzhen, China, KamaxOptic Communication Co. Ltd., well-known as KOC, is specialized in fiber optic communication products and accessories. She offers precise customized solutions for various customers involved in telecommunication, broadcast, CATV and network industry worldwide.

Our quality is guaranteed by the scientific management with the assistances of professional personnel, advanced testing equipments and efficient ERP system under the strict guidance of ISO9001: 2000, from supplier evaluation to inbound material examination, from processing monitoring to permanent inspection, from packing to shipping. We do care for every detail!

To be dedicated to be a popular manufacturer with her quality products, satisfactory services and attention to details through the full commitment of each personnel to work as one team in an effort to exceed our customer expectations.

To operate the business in a transparent and honest manner, that our customers, our associates and our business partners are proud to play their part in our success.

Please visit us website for more information: http://www.koc.com.cn
