Fiber Optic Multi-Fiber Pigtail/ Patch Cord

Name: Fiber Optic Multi-Fiber Pigtail/ Patch Cord
Brand: all-electronics-online.com
SKU: 679249232
Availability: InStock
Rating: 4.6 (66 reviews)

Price:	US $ 5-8/Piece
Trade Terms:	FOB,CIF,FCA
Min Order:	50/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	DTLPMM
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Diameter:	0.9mm,2.0mm,3.0mm
Insert Los:	< 0.20db
Return Loss:	> 50db
Application:	Communication
Type:	Single-mode Fiber
Connection Structure:	FC
Certification:	RoHS

Product Description

Fiber pigtail is a short optical fiber permanently attached to a source, detector, or other fiber optic device at one end and an optical connector at the other.

Ribbon fan-out multi-fiber pigtail

Features:

4, 6, 8, 12, 24, 48 fibers optional
With a fan out kit at the junction of fibers
The fiber is flat type.
Applicable connector: FC, SC, ST, LC
Cable material: PVC, OM1, OM2 or OM3 optional
Single mode or multi mode
Cable size: Φ 0.9mm, Φ 2.0mm, Φ 3.0mm

Application:

Test equipment
Optical CATV & LAN
Telecommunication networks
Optical communication networks

Mode	SM	MM
Polish	UPC/APC	PC
Insertion Loss	Typical ≤0.2dB Maximum ≤0.3dB	≤0.25dB
Return Loss	≥50DB(PC) ≥60DB(APC)	≥30dB
Interchangeability	≤0.2dB
Repeatability	≤0.1dB
Durability	≤0.2dB typical change, 1000 matings
Tensile Strength	> 10kg
Temperature	≤0.2dB (-40+85 sustain 100 hours)
Humidity	≤0.2dB (+25+65 93 R.H.100 hours)

Company exhibition :

Shenzhen Datolink Communication Technology Co., Ltd. Was founded in the January of 2007 by several engineers, who have had many years of working experience in fiber optical as well as in structured cabling industry. Datolink is a high technology oriented company with fiber optical products and structured wiring. We are dedicated to the design, manufacture and sales, meanwhile, we can provide customers with complete cabling solutions in installation and maintenance.

The company has a strict and comprehensive system of quality control and approved the standard ISO9001: 2000. Is well connected with raw materials providers and factories worldwidely, to offer customers a broad line of products with competitive prices and very soon time of delivery.

Our products have been exported to over 20 countries and regions such as Europe, Middle East, Southeast Asia, Latin America, etc. Datolink Ltd is committed to offer the partners high quality products and professional services, we look forward for the successful development with mutual-benefits, for casting the future of fiber optical and structured cabling!
