Fiber Optic Slidable Rack Mount Type Patch Panel 48 Cores

Name: Fiber Optic Slidable Rack Mount Type Patch Panel 48 Cores
Brand: all-electronics-online.com
SKU: 716314185
Availability: InStock
Rating: 5 (107 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,EXW,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	DTLPP -RS48
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	48032089mm
Transmission Medium:	Multimode
Structure:	SC
Number Of Cores:	Multi-Core
Ferrule Endface:	PC(',UPC)
Brand:	Datolink

Product Description

Name: ODF/Fiber Optic Slidable Rack Mount Type Patch Panel 48 Cores

Detailed Product Description:
1. Cold-rolled steel material
2.12, 24, 48 cores and 1U, 2U, 3U height
3. FC, LC, SC, ST adapter optional
4. Standard size, light weight
5. Manufacturer
6. OEM/ODM service

Slidable Rack-mount Fiber Optic Distribution Frame:

Slidable Rack-mount Fiber Optic Distribution Frame has aluminum sliding fittings with self-locking functions prevent the drawer from falling when moved; 19-inch rack mount for ST, SC, LC, MTRJ, FC adapters. The drawer is the holding board for splicing, easy to withdraw the fibers when testing and distributing.

Features:
1. Standard size, light weight and reasonable structure
2. Slide out drawer for easy cable management
3. Suitable for ribbon and single fiber
4. Compact design for space saving
5. Various panel plate to fit different adapter interface
6. Front mark on the plate is easy for identification and operation
7. Easy for management and operation

Application:
1. Telecommunications subscriber loop
2. Fiber to the home (FTTH)
3. LAN/WAN
4. CATV

Ordering information:

Model	Fiber Quantity	Height	Dimension(mm)	Weight(Kg)
DTLPP-RS12	12	1U	450x 320x44.5	4.0
DTLPP -RS24	24	1U	450x 320x44.5	4.2
DTLPP -RS48	48	2U	480x320x89	4.31
DTLPP -RS96	96	2.5U	480x320x110	5.05
