Fiber Optical Attenuator with Mu Connector

Name: Fiber Optical Attenuator with Mu Connector
Brand: all-electronics-online.com
SKU: 679248902
Availability: InStock
Rating: 4.5 (75 reviews)

Price:	US $ 3.2-3.5/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	DTL-PAMUU
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Attenuation Value:	1db to 10db (±1db), 15, 20, 25db
Polarization Loss:	≤0.20 Db
Connector Type:	Sc/FC/St/LC/Mu/MTRJ
Insertion Loss:	<0.20 Db
In-Put Power:	>300 MW
Operating Temp (Degree):	30_+75
Storage Temp (Degree):	-40_+85
Attenuation Accuracy:	+/-0.5(1-10) +/-1.0(11-30)
Operating Wavelength:	Sm: 1310nm, 1550nm
Application:	Network
Type:	Single-mode Fiber
Certification:	ISO9001
Connection Structure:	Mu
Brand:	Datolink

Product Description

Name: MU Fiber Optic Attenuators/Optical Attenuators

Features:

GR-910, UL94-V0 COMPLIANT
Durable For High-Input Power
Ideal For WDM Application
Precise Control of Attenuation Range

Applications:

Power Level Adjustment 0f Optical
Fiber Communication Networks.
EDFA
Dynamic Power Leveling in Optical Add/Drop Multiplexing
Dynamic Power Balancing in DWDM Systems
CATV Systems
Optical Network Equipment
Bi-Directional Systems

Specifications:

Attenuation Accuracy: +/-0.5(1-10) +/-1.0(11-30)
Operating Wavelength: SM: 1310nm, 1550nm
Polarization dependent loss: Less than 0.2dB
Maximum Optical Input Power: 200mW
Operating Temp Range: -40-80 centigrade

Ordering information:

Connector type: SC, ST, FC, LC, MU, MTRJ, DIN
Application: UPC or APC
Plug-in type or male to female type

Connector Type	SC/FC/ST/LC/MU/MTRJ
Operating Wavelength	1310,1550 nm
Attenuation Value	1dB to 10dB (±1dB), 15, 20, 25dB
Optical In-put Power	≥300 mW
Polarization Loss	≤0.20 dB
Return Loss (dB)	P Grade(Return Loss≥50dB) , A Grade(Return Loss≥40dB)
Operating Temp (degree)	-30_+75
Storage Temp (degree)	-40_+85

Shenzhen Datolink Communication Technology Co., Ltd. Was founded in the January of 2007 by several engineers, who have had many years of working experience in fiber optical as well as in structured cabling industry. Datolink is a high technology oriented company with fiber optical products and structured wiring. We are dedicated to the design, manufacture and sales, meanwhile, we can provide customers with complete cabling solutions in installation and maintenance.

The company has a strict and comprehensive system of quality control and approved the standard ISO9001: 2000. Is well connected with raw materials providers and factories worldwidely, to offer customers a broad line of products with competitive prices and very soon time of delivery.

Our products have been exported to over 20 countries and regions such as Europe, Middle East, Southeast Asia, Latin America, etc. Datolink Ltd is committed to offer the partners high quality products and professional services, we look forward for the successful development with mutual-benefits, for casting the future of fiber optical and structured cabling!
