Fiber Optical Curl Patchcord Cabel

Name: Fiber Optical Curl Patchcord Cabel
Brand: all-electronics-online.com
SKU: 823171415
Availability: InStock
Rating: 4.7 (118 reviews)

Price:	US $ 0.2-0.5/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	LC/ FC /SC/ UPC/ APC
Low Insertion Loss:	High Performance
High Exchangeability:	Hight Durability
Transmission Medium:	Single-Mode
Structure:	LC
Number Of Cores:	Single-Core
Ferrule Endface:	PC(Upc)
Shape:	Circular
Fabrication Process:	Moulded
Light Source Type:	Laser
Connector Type:	Sc-PC
Application:	Fiber Distribution Frame

Product Description

APPLICATIONS
Gigabit Ethernet
Telecommunication networks
Active device termination
Video
Industrial
Multimedia
Military
Premise installations

FEATURES
High temperature stability
Good exchangeability
Good Durability
Low insertion loss and back reflection loss
Standard: Telcordia GR-326-CORE

	Single mode	Multimode
Insertion Loss	Typical <=0.2dB, Maximum<=0.3dB	≤0.25dB
Return Loss	≥50 dB (PC) ≥60 dB (APC)
Repeatability	≤0.1
Durability	≤0.2 dB typical change, 1000 matings
Interchangeability	≤0.2dB
Tensile strength	>50N
Operating Temperature	-40 to + 85°C	-40 to + 85°C

ORDERING OPTIONS

Boot(cable)Size	Boot Color	Fiber Type	Cable number	Application	Length
0.9mm	Beige	9/125µm (SM)	Simplex	PC	Customized
2.0mm	White	50/125µm (MM)	Duplex	APC
	Blue	62.5/125µm (MM)

Shenzhen KOC Communication Co., Ltd. Is specialized in fiber optic communication product manufacture. Our products range from the basic components to end products, including passive and active categories as follows: Basic Components: Connector kits, Adapter kits, Attenuator kits.

Passive products: Connector, Adapter, Attenuator, Patch-cord, ODF and enclosure.

Active products: Media converter, Transmitting and receiving assemblies, such as laser diode assembly, PD and PIN/TIA assembly, sub-assemblies such as TOSA, ROSA, BOSA.

FTTH System: Gpon: OLT, ONU, PLC

Headquarter located in Shenzhen, China, we have branch companies, representatives and distributors in Europe, America, Middle East, South Asia. KOC products are well accepted and sold in these areas.

We provide all our products with high quality, competitive price, short delivery lead time and excellent after-sales services.

About KOC

Located in Shenzhen, China, KamaxOptic Communication Co. Ltd., well-known as KOC, is specialized in fiber optic communication products and accessories. She offers precise customized solutions for various customers involved in telecommunication, broadcast, CATV and network industry worldwide.

Our quality is guaranteed by the scientific management with the assistances of professional personnel, advanced testing equipments and efficient ERP system under the strict guidance of ISO9001: 2000, from supplier evaluation to inbound material examination, from processing monitoring to permanent inspection, from packing to shipping. We do care for every detail!

To be dedicated to be a popular manufacturer with her quality products, satisfactory services and attention to details through the full commitment of each personnel to work as one team in an effort to exceed our customer expectations.

To operate the business in a transparent and honest manner, that our customers, our associates and our business partners are proud to play their part in our success.

Please visit us website for more information: http://www.koc.com.cn
