Fiber SMA905 Fiber Optic Connector For High Power
| Price: |
US $ 2-2.7/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
PN985 |
| Color: |
Black |
| Material: |
Metal |
| Fiber Count: |
1 Cores |
| Fiber Type: |
Singlemode |
| Tensile: |
1000N |
| Fiber Polishing: |
APC |
| Cable: |
2.0mm/3.0mm |
| Type: |
Single-mode Fiber |
| Connection Structure: |
SMA905 |
| Material Shape: |
Round Wire |
| Allowed Lateral Pressure: |
>1000（N/100mm） |
| Allowed Tensile Strength: |
1000N<10000N |
| Core: |
Double Core |
| Certification: |
CE, RoHS, ISO9001, UL |
| Sheath Material: |
Metal |
| Connector Type: |
SMA905 |
| Application: |
Art, Sensor, Communication, Medicine |
Product Description
Fiber SMA905 Fiber Optic Connector For High Power
Fiber Optics, the one who started it all. Big industries rely on this piece of innovation, and PUNO Fiber optics is the go - to place for high grade innovations. Its main features include mode stripper, free-standing fiber and adhesive-free. Easy to install and maintain. Compatible with standard laser systems. And this kind of SMA 905 fiber optic connector for use with Aluminum buffered 200μm fiber size.
Features / Benefits:
High Precision SMA905 ferrule;
Optional Stainless steel tube or PVC protecting jacket;
Variety option of large core optical fiber.
Typical application:
Semiconductor laser tail fiber;
High power laser flexible transmission;
Laser welding, cutting,
Atmospheric spectrum measurement;
Infrared temperature measurement;
The products are widely used in industrial laser equipment, medical laser equipment, and other high power energy transmission system energy electronic field. May according to the customer request processing production of connection type optical fiber transmission line.
Specifications:| Compliance | IEC 61754-15, TIA 604-16 |
| Technology | Full ceramic ferrule and sleeve |
| Tuning | in 60° steps |
| Mechanical resistance | 100N tensile load |
| Thermal resistance | -40ºC to +85ºC, stock temperature range |
| Flammability | UL 94-V0 |
| Durability | Min. 1000 mating cycles |
Color of housing | Single-mode, Black |
| SM (APC 8°), green |
| Multimode, beige |
Cable Parameter:| No. | Items | Unit | Specification |
| G.655E |
| 1 | Mode Field Diameter | 1550nm | μm | 8.0~11.0±0.6 |
| 2 | Cladding Diameter | μm | 125.0±1.0 |
| 3 | Cladding Non-Circularity | % | ≤1.0 |
| 4 | Core-Cladding Concentricity Error | μm | ≤0.6 |
| 5 | Coating Diameter | μm | 245±10 |
| 6 | Cladding-Coating Concentricity Error | μm | ≤12.5 |
| 7 | Cable Cutoff Wavelength | nm | λcc≤1450 |
Payment & Shipping Terms:| Minimum Order Quantity | 1 Piece MOQ On Request |
| Packaging Details | 10 or 20 PCS / Plastic Tray, 1 PC / Gift Box |
| Delivery Time | Delivery In 7 - 15 Business Days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 5000 Pieces Per Monthly |
Ordering Information:A:
Ferrule type | B:
Fiber Length (m) | C:
Fiber Specifications | D:
Fiber Jacket | E:
Dust Cap | F:
Transmission Wavelengths | G:
Transmission power |
C:Ceramic
S:Stainless steel | 1
2
3
x-Customization | SM:9/125um Single Mode SM
OM1:62.5/125um Multimode MM
OM2:50/125um Multimode MM
SI 40/125-22/220
SI 100/140-22-250
SI 105/125-22/250
SI 200/220-22/500
SI 300/330-22/500
SI 400/440-22/730
SI 800/840-22/1100
X-Refer to fiber specification | 3P:3.0mm PVC Jacket
3S:3.0mm PVC metallic armorer
6:6.0mm stainless steel armorer | M:Metal Dust Cap
P:Plastic Dust Cap | X- Customization | X- Customization |
