Finned Heaters/ Immersion Heaters

Name: Finned Heaters/ Immersion Heaters
Brand: all-electronics-online.com
SKU: 690575881
Availability: InStock
Rating: 4.5 (28 reviews)

Price:	Negotiable/Piece
Min Order:	50/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	customize

Product Description

Overview
Quick Details

Condition	New
Place of Origin	Shezhen,China
Dimension	Custom Size
Power(W)	200-5000W
Type	Air Heater
Brand Name	Superb Heater
Certification	CE ROHS
Tube diameter	6-20MM

Power tolerance	-5%-10%
Fin Pitch	3mm, 5mm, 10mm or Customize
Power Source	Electric
Voltage	220V or Customize
warranty	1 year
Material	SS304,SS321,SS316
Fin Thickness	0.3-1mm
Shape	Square, Round, Strip

Product Description
Product Application of Finned Tube Duct Heater
Finned tubular air heater is designed for use in natural and forced convection space heating. our range of finned air heaters are suitable for increased heat transfer surface area and where higher wattage is required. Featuring rugged construction, these finned heaters can be used in a multitude of industrial environments.
Finned tubular heaters are used for forced convection heating, air or gas heating heating systems. Finned tubular heaters/heating elements are customized to meet your specific application needs.

Specifications of Finned Tube Duct Heater
1.Tube diameter: Φ6mm-Φ30mm
2.Tube Material: SS201, SS304, SS316, SS321 and INCOLOY800 etc
3.Insulation Material: MgO
4.Conductor Material: Nichrome Resistance Wire
5.Wattage Density: High/Middle/Low (5-25w/cm2)
6.Lead Connection Option: Threaded Stud Terminal or Lead Wire
7.Lead Wire Type: 300mm Standard (Teflon/Silicone High Temperature Fiberglass are available for Finned Tubular Heater)

Main Features of Finned Tube Duct Heater
1. Mechanically-bonded continuous fin assures excellent heat transfer and helps prevent fin vibration at high air velocities.
2. Several standard formations and mounting bushings available.
3. Standard fin is high temperature painted steel with steel sheath.
4. Optional stainless steel fin with stainless steel or incoloy sheath for corrosion resistance.

Shenzhen superb heater technology Co., Ltd, Founded in 1985, Start is a state run Magnesium Oxide factory, After privatization reform To become a professional to provide all kinds of electric heating products of the comprehensive private joint-stock companies, After years of development company now grown to have include: ChaoHu heating material fitting, JiuDing machinery and spare parts, LiLin cartridge heaters, chaohu band coiling heaters, JXC Industrial heaters five plants, more than 200 employees, assets of more than $ 5 million, Products include various types of industrial heater, cartridge heater, hot runner, thermocouples, band heater and a variety of heater materials and heater equipment to meet customers one-stop shopping for all kinds of heating element, heating materials and heating equipment needs.

Over the years we are committed to technology and product quality improvement, many products similar products meet international quality, in China in the lead, swaged-in leads cartridge heater and diameter less 4mm cartridge heater as China's first single, cost-effective products to give our customers highly recognized, it has been to establish and maintain long-term cooperative relations with more than 700 customers in over 40 countries.

We will insist on our stable style to establish good image in both customers and our partners. We have been insisting on the "REDUCING THE COST AND GIVING ADVANGTAGE TO CUSTOMERS " To provide customers with better products and services, and grow with customers

After long-term accumulation, we have set up agents and partners in India, Dubai, USA, Russia, Brazil, Argentina, Thailand, Korea and other countries to provide convenient and quick service
