Fixed Wireless Terminal

Name: Fixed Wireless Terminal
Brand: all-electronics-online.com
SKU: 746813325
Availability: InStock
Rating: 4.6 (37 reviews)

Price:	US $ 0.025/Piece
Trade Terms:	FOB,CIF
Min Order:	100/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	AWG22-16 fixed wireless terminal
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Place Of Origin:	Zhejiang China (Mainland
Model:	AWG22-16 Crimp Terminal
Color:	Red, Blue, Yellow, Black
Thickness:	Thickness
Insulation:	Flame Retardant PVC (Polyvinyl Chloride
Working Temp:	-40 To105°c
Cable Range:	3.2mm-8.4mm
Delivery Detail:	15 Days After Getting Deposit
Supply Ability:	1,000,000 PCS Per Week
Test Report:	Reach, RoHS
Application:	Conduct Electricity
Type:	Single Hole Terminals
Material:	Copper
Brand:	CNC

Product Description

Fixed wireless terminal

Strong weld intensity, good nature in electrification, resistant galvanic corrosion and long service life; High quality.
Feature:

1. DTL series of copper-aluminim wiring terminals are suitable for transition connection of the circular aluminium wires, hemicycle-sector aluminium wires.

2. Power supply cables in the distribution equipment and copper terminals of the electrical equipment.

3. The material of aluminium and copper is that of L2 and T2 respectively.

4. The technology of friction welding is wonderfully adopted.

5. Therefore they have distinguishing features of strong weld intensity, good nature in electrification, resistant galvanic corrosion and service life.
Lead section: 0.5-1.5mm2(22-16) Max current: 9A
TypeNumber of ANSI boltDiameter of bolt mouth d2
RV1.25-3#3.2mm
RV1.25-3.5#3.7mm
RV1.25-3.5#3.7mm
RV1.25-3.5#4.3mm
RV1.25-4#4.3mm
RV1.25-4#4.3mm
V1.25-5#5.3mm
RV1.25-61#. 3mm
RV1.25-85#. 5mm
RV1.25-103#. 5mm
Lead section: 1.5-2.5mm2(16-14) Max current: 27A
TypeNumber of ANSI boltDiameter of bolt mouth d2
RV2-3#3.2mm
RV2-3.5#3.7mm
RV2-3.5#3.7mm
RV2-3.5#4.3mm
RV2-4#4.3mm
RV2-4#4.3mm
RV2-5#5.3mm
RV2-5#5.3mm
RV2-61#6.5mm
RV2-83#8.4mm
Lead section: 2.5-4mm2(14-12) Max current: 37A
TypeNumber of ANSI boltDiameter of bolt mouth d2
RV3.5-4#4.3mm
RV3.5-5#5.3mm
RVL3.5-5#5.3mm
RV3.5-61/6.5mm
Lead section: 4-6mm2(12-10) Max current: 48A
TypeNumber of ANSI boltDiameter of bolt mouth d2
RV5.5-3.5#3.7mm
RV5.5-4#4.3mm
RV5.5-4#4.3mm
RV5.5-5#5.3mm
RV5.5-61/6.5mm
RV5.5-85/8.4mm
RV5.5-103/10.5mm
RV5.5-121/13.0mm
Package of ring terminal
