| Prod Model: |
electrical wire |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Electrical Wire 2.5sq.mm: |
Max. DC Resistance @ 20 Degree 7.41 Ohm/Km |
| Electrical Wire 4sq.mm: |
Max. DC Resistance @ 20 Degree 4.61 Ohm/Km |
| Supplier: |
Factory |
| Certificate: |
Ce, ISO |
| Conductor: |
Round Copper Wire |
| Insulation: |
PVC |
| OEM Service: |
Yes |
| Package: |
100 M/Roll |
| Payment: |
T/T |
| MOQ: |
2000 M/Size |
| Type: |
Insulated |
| Application: |
Underground |
| Conductor Material: |
Copper |
| Insulation Material: |
PVC |
| Certification: |
CCC |
| Range Of Application: |
Heating or Underground |
| Brand: |
Jytop |
| Sheath Material: |
No |
| Conductor Type: |
Class 5, Flexible |
Product Description
Flexible Electrical Wire with Copper Conductor
Flexible Electrical Wire with Copper Conductor, PVC insulated electric wire with Class 5 conductor PVC insulated
Flexible Electrical Wire with Copper Conductor is a flexible PVC cable used for switch control in relay and instrumentation panels of power switchgear and is used for purposes such as internal connectors in rectifier equipment, motor starters and controllers.
Construction:
Conductor: Flexible class 5 copper conductors to BS6360
Insulation: PVC
Temperature Rating: 70°C
Voltage Rating: H05V-K for 300V ac and 500V dc; H07V-K for 450V ac and 750V dc
Minimum Bending Radius : 6 x overall diameter.
Colour : Black, Blue, Green/Yellow, Red, Yellow, White, Violet, Brown, Grey, Orange, Pink.
Packaging - 100, 500, 1,000 metre reels. Barrels and other lengths available upon request.
Flexible Electrical Wire with Copper Conductor specifications(data sheet,table,full form)
JYTOP Cable is a professional 2491X (Single Core Copper Conductor PVC Insulated Flexible Cable factory) manufacturer and supplier in China.Our products also include: AAC,AAAC,ACSR,ACAR, Galvanized Steel Wire, Aluminium Clad Steel Wire, PVC wire, PVC/XLPE power cable, Aerial Bundled Cable, rubber cable, control cable, etc. Any Interested, Pls feel free to email us,we will reply to you that day feasible prices and material in time!
| Size of conductor | Nominal thickness of insulation
mm | Mean overall diameter
Upper limit
mm | Approx.net weight per km
kg |
Nominal
cross-sectional area
mm 2 | Number and diameter of wires
no./mm |
| 1.0 | 32/0.20 | 0.6 | 3.0 | 16 |
| 1.5 | 30/0.25 | 0.7 | 3.5 | 21 |
| 2.5 | 50/0.25 | 0.8 | 4.2 | 33 |
| 4 | 56/0.30 | 0.8 | 4.8 | 50 |
| 6 | 84/0.30 | 0.8 | 6.3 | 70 |
| 10 | 80/0.40 | 1.0 | 7.6 | 120 |
| 16 | 126/0.40 | 1.0 | 8.8 | 175 |
| 25 | 196/0.40 | 1.2 | 11.0 | 290 |
| 35 | 276/0.40 | 1.2 | 12.5 | 400 |
| 50 | 396/0.40 | 1.4 | 14.5 | 565 |
| 70 | 360/0.50 | 1.4 | 17.0 | 770 |
| 95 | 475/0.50 | 1.6 | 19.0 | 1010 |
| 120 | 608/0.50 | 1.6 | 21.0 | 1260 |
| 150 | 756/0.50 | 1.8 | 23.5 | 1580 |
| 185 | 925/0.50 | 2.0 | 26.0 | 1900 |
| 240 | 1221/0.50 | 2.2 | 29.5 | 2500 |
Zhengzhou JINYUAN Wire and Cable Co., Ltd, as a professional cable manufacturer. We have get ISO9001 and CE certificates. Our Professional and complete cable solutions make JYTOP Cables become to the partner of choice for international companies around the world,
PRODUCTS & STANDARDS & International Market:
1). Bare Conductor:
All Aluminum Conductor (AAC),
All Aluminum Alloy Conductor (AAAC),
Aluminum Conductor Steel Reinforced (ACSR),
Aluminum Alloy Conductor Steel Reinforced (AACSR),
Aluminum Conductor Aluminum Coated Steel Reinforced (ACSR/AW),
Aluminum Conductor Aluminum Alloy Reinforced (ACAR),
Aluminum Conductor Steel Supported (ACSS),
Aluminum Conductor Aluminum Coated Steel Reinforced (ACSR/AW)
All Copper Conductors(ACC),
Aluminum Coated Steel Wire(ACS),
Copper Coated Steel Wire(CCS),
Copper Coated Aluminum(CCA),
Galvanized Steel Wire(GSW),
Enameled Wire - Enameled round Aluminum Wire & Enameled round copper Wire
2). Overhead Cable:
Aerial Bundled Cable (ABC).
XLPE Cable,
Flexible Cable,
Single Core Cable,
2 Core Cable,
3 Core Cable,
4 Core Cable.
3). Building wire and cable:
THHN /THWN Cable
TW/THW Cable
PVC Insulated Wire,
XLPE Insulated cable.
4. Power Cable:
Armored /Non-armored Power cable
AWA Cable
SWA Cable
Standards: IEC, ASTM, AS/NZ, SANS, BS, DIN, NF, JISC, etc.
We can meet customers' special requirements, and provided OEM service.
Mainly Oversea Marketing: Southeast Asia, The Middle East, Africa, South America, so on.
We will be recognized as a professional Manufacturer in cable industry, through continuous improvement of our product quality, after sales service. We can give you the reliable solution for cable wires.
Company website: www.jytopcable.com
