| Prod Model: |
XJY-PCB 196 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Surface Finishing: |
Enig |
| Copper Thickness: |
35um |
| Board Thickness: |
0.2mm |
| Min. Hole Size: |
0.2mm |
| Min. Line Wigth: |
0.1mm |
| Min. Line Spacing: |
0.1mm |
| Layer: |
2 |
| Color: |
White, Yellow, Ect |
| Certificate: |
UL, RoHS, SGS, ISO9001 |
| Package: |
Vacuum |
| Structure: |
Double-Sided FPC |
| Material: |
Polyimide |
| Conductive Adhesive: |
Conductive Silver Paste |
| Application: |
LED |
Product Description
Welcome to XJY------------- Shenzhen Xinjiaye Electronics Technology Co., Ltd is a professional pcb manufacturer has over 10 years experience. We are able to offer 1 to 24 Layer PCB, ranging from pcb produce, components purchase, pcb assembly, pcb copy service.Our products are widely used in communication apparatus, automobile electronics, auto parts, computers, medical devices, light systems, outdoor systems, network devices and consumer electronics class fields. Quick Details
| Place of Origin: | Guangdong, China (Mainland) | Brand Name: | XJY | Model Number: | xjy-pcb 196 |
| Base Material: | Aluminum | Copper Thickness: | 1OZ | Board Thickness: | 0.2mm |
| Min. Hole Size: | 0.2mm | Min. Line Width: | 0.1mm | Min. Line Spacing: | 0.1mm |
| Surface Finishing: | Immersion gold | flexible pcb: | fpc assembly | fr4 stiffener fpc: | fpc with metal domes |
| 2-layer fpc: | double-sided fpc | 1-layer fpc: | singe layer fpc | multilayer fpc: | fpc with goldfinger |
Capacity
Testing Procedures For FCB Board---We perform multiple quality assuring procedures before shipping out
Any PCB board. These include:
* Visual Inspection
* Flying probe
* Bed of nails
· * Impedance control
· * Solder-ability detection
* Digital metallograghic microscope
· *AOI (Automated Optical Inspection)
Detailed Terms for PCB Manufacturing---Technical requirement for PCB assembly:
* Professional Surface-mounting and Through-hole soldering Technology
* Various sizes like 1206, 0805, 0603 components SMT technology
* ICT(In Circuit Test), FCT(Functional Circuit Test) technology.
* PCB Assembly With UL, CE, FCC, RoHS Approval
* Nitrogen gas reflow soldering technology for SMT.
* High Standard SMT&Solder Assembly Line
* High density interconnected board placement technology capacity.
Delivery Time for FPC board1) FPC production time: Sample: 2-3 days / mass production: Within 7 days
2) Components purchase: 2 days if all components is available in our domestic market.
3) FPC Assembly: Samples: Whthin 2 days / mass production: Within 5 days
Quotation Requirement:Following specifications are needed for quotation:
A) Base material:
B) Board thickness:
C) Copper thickness
D) Surface treatment:
E) color of solder mask and silkscreen:
F) Quantity
Shipping Method and Payment terms:1. By DHL, UPS, FedEx, TNT using clients account.
2. We suggest you using our DHL, UPS, FedEx, TNT forwarder.
3. By EMS (Usually for Russia Clients), price is high.
4. By sea for mass quantity according to customer's requirement.
5. By customer's Forwarder
6. By Paypal, T/T, West Union, etc.
FPC Process Capability· Processing layers: 1-6 layers
· Finished thickness (thinnest): 3mil (0.08mm)
· Minimum aperture: 4mil (0.10mm)
· Minimum line width / spacing: 2 mil (0.05mm)
· Maximum board size: 10 "x 45" (250x 1200mm)
· Surface Treatment: OSP, HASL, Electric Nickel / Gold, , Chemical nickel / gold, lead-free HASL, Immersion Gold
· Insulation resistance: ± 1011Ω (Normal Normal
· Thermal shock resistance: 260 ° C 10 sec.
· Processing materials: Polyimide (PI), polyester (PET), polyimide (PI) + FR4
Double sided flexible circuit (FPC)Consists of double-sided copper clad material with top and bottom cover films (PI or Green/Yellow Oil, Carbon Ink, etc).
Two conductive layers with an insulating layer between, plus conver layers on outer layer. The cover
Films are pre-routed to access copper from both sides using plated thru holes(PTH).
Other Service:A) We have many special material as rogers, teflon, taconic, Fr-4 high tg, Ceramic in stock. Welcome to send us your inquiry.
B) We also provide sourcing components, PCB design, PCB copy, PCB drawing, PCB assembly and so on. So provide sourcing components, PCB design, PCB copy, PCB drawing, PCB assembly and so on.
If you hve any need for PCB & PCBA,PLS feel free to contact me!
