| Colour: |
Orange |
| Voltage&Wattage: |
Customized |
| Temperature: |
0-250°c |
| Thickness: |
1.5-4mm |
Product Description
Specifications for Silicone Rubber Heater
The Silicone rubber fiberglass insulated flexible heaters can improve heat transfer and speed warm-ups where controlled heating is required in confined areas. Two circuit designs are available: etched foil or wire wound.
Silicone rubber heater
Silicone rubber heater produced by superb heater is extremely thin, light and flexible. And the heater with the silicon rubber electric heating plate can transfer heat to any required place. In processing, it can improve heat transfer, accelerate temperature rising and reduce power need. Glass fiber-reinforced silicon rubber can ensure the heater to be stable in dimension, without losing flexibility.
(1) Design according to actual shape and dimension, and adopt three-dimensional geometry to satisfy the requirements of your equipment.
(2) Moisture-proof chemical defense silicon rubber material makes the service life of heater much longer.
(3) It can be simply pasted or attached to your component by vulcanizing, adhesive or fastener, etc.
| Temperature Rating | 250°C maximum operating |
| Size/Shape Limitations | Min size 20mm*20mm |
| Thickness | ~0.06 inch(Single-Ply)~0.12 inch(Dual-Ply) |
| Voltage | Any AC or DC |
| Wattage | Customer specified(Normal maximum of 0.8-1 watts per square mm) |
| Power lead wire | Silicone rubber, SJ Power Cord, or Teflon insulated stranded wire |
| Attachment | Hooks, lacing eyelets, Or Velcro closure. Temperature control(Thermostat) |
Description | 1. Thinness, lightness, sticky and flexibility
2. Improve heat transfer, accelerate warming and decrease power under the process of operation
3. Heat fast and high thermal conversion efficiency |
Features for Silicone Rubber Heater
(1) Heating fast and long time using
(2) Flexibility and customized shape
Dual Voltage, Zoning and Three Phase for Silicone Rubber Heater
Due to the flexibility in circuit design of Silicone Rubber Heater, multiple heating circuits can be designed to accommodate dual voltage and multiple zones. On dual voltage heaters, three leads, including a common in a different color, are provided for wiring the heater in series for the higher voltage and parallel for the lower voltage. 120/240 Vac or 240/480 Vac can be achieved. Multiple circuit areas can be zoned to achieve different heating effects. Three-phase circuits can also be designed for high current applications.
Our Services
One year warranty
Fast delivery and competitive price
FREE assistance for design to achieve an ideal thermal heating solution
Customized size,shape and voltage&wattage |
Technical Data
| Rated Power | Customized | Lead Length | 200mm |
| Rated voltage | 12V-380V | Wire tension | 15N×15N |
| Maximum size | 1000m-1200m | Minimum size | 20mm×20mm |
| Ambient Temperature | --60-----250ºC | Highest temperature | 250ºC |
| Maximum thickness | 1.5mm-4mm | Withstand voltage | 1.5KV |
| Insulation resistance | ≥5MΩ | Size deviation | ±0.5% |
| Power deviation | ±5% | Wire Type | Silicone braided wire |
Product Specification| | Oil Drum Heater
200Liter | Oil Drum Heater
20Liter | Oil Drum Heater
200Liter | Oil Drum Heater
200Liter |
| Size | 250×1740 | 200×860 | 125×1740 | 150*1740 |
| Capacity | 200V 2000W | 200V 800W | 200V 1000W | 200V 1000w |
| The temperature regulates | 30~150ºC |
| Weight | Invite:0.5kg | Invite:0.4kg | Invite:0.3kg | Invite:0.35kg |
When inquire, please specify:
1.Size and shape of the heater you need;
2.Power or temperature of the heater you need;
3.Working environment;
4.Quantity of the heater you need;
5.Special requirements if you have.
Why Choose USSuperb Heater Technology has been focused on the production of silicone rubber heater for wvo oil biodiesel plastic metal barrel since 1985, which is well-known as one of the leading manufacturers and suppliers of silicone rubber heater for wvo oil biodiesel plastic metal barrel. In the past years, we owned strong reputation for the high quality, reliable performance and strong durability of our products. Should you are interested, please feel free to contact our factory.
Shenzhen superb heater technology Co., Ltd, Founded in 1985, Start is a state run Magnesium Oxide factory, After privatization reform To become a professional to provide all kinds of electric heating products of the comprehensive private joint-stock companies, After years of development company now grown to have include: ChaoHu heating material fitting, JiuDing machinery and spare parts, LiLin cartridge heaters, chaohu band coiling heaters, JXC Industrial heaters five plants, more than 200 employees, assets of more than $ 5 million, Products include various types of industrial heater, cartridge heater, hot runner, thermocouples, band heater and a variety of heater materials and heater equipment to meet customers one-stop shopping for all kinds of heating element, heating materials and heating equipment needs.
Over the years we are committed to technology and product quality improvement, many products similar products meet international quality, in China in the lead, swaged-in leads cartridge heater and diameter less 4mm cartridge heater as China's first single, cost-effective products to give our customers highly recognized, it has been to establish and maintain long-term cooperative relations with more than 700 customers in over 40 countries.
We will insist on our stable style to establish good image in both customers and our partners. We have been insisting on the "REDUCING THE COST AND GIVING ADVANGTAGE TO CUSTOMERS " To provide customers with better products and services, and grow with customers
After long-term accumulation, we have set up agents and partners in India, Dubai, USA, Russia, Brazil, Argentina, Thailand, Korea and other countries to provide convenient and quick service
