Ningbo Zhongda Leader Intelligent Transmission Co., Ltd. >> Floor Sweeping Machine DC 24V Motor

Floor Sweeping Machine DC 24V Motor

Floor Sweeping Machine DC 24V Motor
Price: Negotiable/Piece
Trade Terms: FOB,others
Min Order: 1/Piece
Pay Type: T/T
Prod Model: Floor Sweeping Machine DC 24V Motor
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Protection Class: IP20, IP54

Product Description

MAIN DATA
No-load noise of motor: <65dB, L=100cm
Voltage enduration: AC2500V, 1S
Leaking current: <5mA
Insulation resistance: >500MΩ 500V
Gear ratio: 7&10
Features:
The material of rotor is 40Cr, quench to HRC50-55 after rough rolling, two times hard cutting, the gear precision can arrive ISO class6-7.
The material of shaft gear is 20CrMnTi, quench to HRC58-61 after rough rolling, two times hard cutting, the gear precision can arrive ISO class6-7.
The material of plate gear is 40Cr, quench to HRC48-51 after rough rolling, grind, the precision can arrive ISO class6-7.



Mode

Voltage



V

Power



  W

No-load Parameters

Load Parameters

Motor Weight

  Kg

Speed

r/min

Current

A

Speed

  r/min

Torque mN. m

Current

    A

ZDSDJ750W-220

220/50Hz

750

1490

Max0.8

1410

5.1

4.60

9.0

ZDSDJ750W-100

100/60Hz

750

1790

Max4.5

1720

4.2

9.85

9.0

ZDSDJ1100W-220

220/50Hz

1100

1490

Max1.0

1410

7.5

4.80

10.5
Ningbo zhongda leader transmission equipment Co., Ltd. is specialized in mini AC gear motors. At present, our main products are: Gear motors, three phase motors, speed control motors, brake motors, damping motors, torque motors, and DC gear motors. They are widely used in machine tools, textile machinery, medical appliance, conveying machines, printing mechanism, food machinery, vending machines, packing machinery, and gumming machines.

Our tenet is: Quality as foundation, reputation first, seeking for outstanding position. With excellent equipment, advanced procedure, scientific management, and modern test method, we can provide all customers both at home and abroad with our top quality products, favorable prices and sincere service.

We welcome interested companies to inquire about our products. We are looking forward to establishing long-term business relationships together with you for mutual business success.

History of ZD motor:

March 1996, start to make motor parts;

1998 start to make Y-series AC motor;

2001 start to produce micro AC gear motor;

2005 start to customize products for customer. Meanwhile, start to produce DC gear motor;

2006 start to produce small series AC gear motor;

2007 start to produce planetary gearbox and BLDC motor;

ZD is the first draft-man of national standardin 2008;

ZD is the first draft-man of standard in 2010;

ZD developed China's first high-precision helical planetary gear reducer in 2011;

ZD developed a robot-specific reducer in 2011.

Honors:

Ningbo's well-known trademarks;

Ningbo technology innovation model.

Ningbo patent demonstration enterprise;

Ningbo innovative pilot enterprises;

Ningbo Safety Standardization enterprises;

Chinese micro motor Union;

Chinese gear Union;

Chinese Electric parts Union;

Chinese Micro motor standardized Union;

First draft-man of Chinese standard of micro motor
