Flush Diaphragm Pressure Transmitter for Liquid

Name: Flush Diaphragm Pressure Transmitter for Liquid
Brand: all-electronics-online.com
SKU: 726083375
Availability: InStock
Rating: 4.5 (113 reviews)

Price:	US $ 1-11/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	PT-F002
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Pressure:	0~0.5bar and 0~70bar
Overload Pressure:	1.5×full Scale
Accuracy:	0.25%F.S
Power Voltage:	12~30VDC

Product Description

Characteritic
Pressure range: 0~0.5bar and 0~70bar
Excellent long term stability
Excellent linearity
Small thermal effect
Application: Chemical and foodstuff industry, paper industry

Technical Parameter

Pressure range	Gauge Pressure: 0~0.5bar and 0~70bar
Overload pressure	1.5×full scale
Accuracy	0.25%F.S., 0.5 %F.S
Power voltage	12~30VDC, 24VDC
Output signals	4~20mA, 0~10mA, 1~5VDC, 0~10VDC, 0~5VDC, customer
Compensated temperature	0~50ºC ,-10~80ºC ,customer
Media temperature	-25~85°C
Environment temperature	-30~85ºC
Storage temperature	40~125ºC
Temperature influence	0.02%F.S./ ºC
Electrical connection	DIN, M12×1(4-pin), Terminals, customer
Protection class	IP65, IP67
Mechanical connection	Clamp DN1", DN1 1/2", DN2", G1"(M), G1/2(M), customer
Vibration	20g, 20~5000HZ
Shock	100g, 11ms
Housing material	SUS304, Aluminum alloy
Operating life	1×108 Pressure cycles

About us:
Founded in 2009, our company is committed to supplying a full range of pressure switches / transmitters / sensors, level switches / transmitters/ meters, flow switches / transmitters/ meters.
Our company is located in the "Capital of Electric Products", Liushi, Wenzhou. Besides, we set branch in Shanghai for automation control business in 2013.

Shanghai Office
ADD: Rm. 408, #1 Building, Shanghai Zhihui Science Park, No.11, lane 911, Hulan Road, Baoshan, Shanghai
Zipcode: 201900

Liushi Office
ADD: ROOM A111, JINHAO BUILDING,No.1-8 LIUWENG ROAD,LIUSHI ,YUEQING,WENZHOU
Zipcode: 325604

Yiwu Office
ADD: No. 146-3, Chouzhou North Road, Yiwu, Jinhua

Taizhou Office
ADD: No. 7, Xianqian Road, Yuhuan, Taizhou

More information, you can browse our website: www.bingo-sensor.com
