Food Class Sharp Head PT1000 Rtd Sensor for Meat Probe

Name: Food Class Sharp Head PT1000 Rtd Sensor for Meat Probe
Brand: all-electronics-online.com
SKU: 732488512
Availability: InStock
Rating: 5 (72 reviews)

Price:	US $ 0.01-1/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Production Process:	Encapsulation
Material:	Resin

Product Description

Quick Details:

Place of Origin:	Hefei, China (Mainland)	Brand Name:	Focusens	Model Number:	6828
Usage:	Temperature Sensor	Theory:	Resistance Sensor	Output:	Digital Sensor
Resistance:	PT100,PT1000	Accuracy:	A, B class	Response Time:	4S
Shell Tpye:	Stainless steel	Shell Size:	4X20mm or as required	Connector:	As required
Wire material:	Teflon or silicon wire	Wire Length:	1000mm or as required	Temperature Range:	-30~250 celsius

Packaging & Delivery:

Packaging Details:	Packed in strong poly bags, several bags packed in standard high press-resistance box. Each box will take 4 belt. And we will put the sticker of sensor specification attached. Box Size: 460335350mm or customized
Delivery Detail:	Within 20 workdays for first order, 10~15 workdays for repeat orders

Specifications:
PT100 waterproof RTD high temperature sensor
1. Waterproof better
2. Fast response
3.1% accuracy
4. Manufacturer

PT100 Temperature Sensor Specifications:

R0 Value:	100 Ohm
R100 Value:	138.5 Ohm
Shell Type	Injection Molding------IP68 grade of waterproof Expoxy-----mainly used for indoor Metal(stainless steel, Ni-Cu, Cooper)-----fast response, there are different shapes: Bullet type, cylinder type, surface mounting type, screw type, Megestism type, Clamp type. Plastic-----good in low temperature
Application	Air conditioner, refrigerator, frozen cabinet, microwave oven, electric brooder, washing machine Water heater, dishwasher, bread maker, disinfecting machine, soybean milk machine etc
Features	1. Wide operating temperature range, good stability and reliability. 2. Easy to installation and manipulation as the sealing can be done according to environment And conditions there it is applied by customer. 3. Accurate testing can reflect temperature change precisely. 4. Insulating resistance(MΩ): Over 100MΩ at DC500 V 5. Working temperature range(°C): -50 to +250 6. Dissipation factor(MW/°C): 1-2 (in still air) 7. Thermal time constant(s): Within 10-20 sec (in air)

In order to help you get the exact model, please offer the following necessary info.:
1. The application of the thermistor: __________
2. Working environment of thermistor: ________
3. The range of operation temperature: ___°c to ___°c
4. The dimension and the drawing of the Thermistor

Other Prodcucts:

Focusens is a ISO certified and patented company specially works in developing, producing and service of temperature sensors and thermal components.

With more than 15 years field experience, we are committed to provide quality and prompt delivery of temperature and humidity components, as well as custom design service in temperature humidity field.

Our activities covers all over the world, including Asia, Europe, America, Latin America, Australia and South Africa.

Our customers covers Important players such as Schneider, Oster, Haier, Lada, JAC etc.

Our main products including various temperature sensors and temperature sensing element, various output type humidity transducer, and temp. Humidity monitor and control units.

We provide professional design, manufacturing, and assembly, meanwhile accept OEM with customers design.

Contact us now for details and improve projects efficiency with our expertise.
