Fork Type No Automatic Reset Limit Switch with CE

Fork Type No Automatic Reset Limit Switch with CE
Price: US $ 2.9-3.6/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 50/Piece
Pay Type: L/C,T/T,Paypal,Money Gram,Western Union
Prod Model: LXK3-20S/H1\H2\H3
Markets: North America,South America,Eastern Europe,Africa,Oceania,Western Europe
Frenquency: 10-55Hz
Protection Degree: IP65
Rated Value: Rated Insulation Voltage Ui-380V
Manufacturer: OEM
Condition: Original New
Protection Angle: 360
Amplitude: 0.75mm
Protection For Short-Circuit: Rated Fuse Current 100arl1-15/10
Operation Frequency: AC 2400 Times Per Hour, DC 1200 Times Per Hour
Protection: Waterproof
Size: Small-Sized
Environment: ﹤250℃
Breaking Capacity: Micro-Current
Breaking Form: Single Type
Pressing Type: Rotary
Application: Widely Used
Brand: Winston

Product Description

The product is to service at such control circuit as AC50~60Hz, voltage of 380VAC or 220VDC and current of 10A to automatically control machine tool, limit movement and action of drive mechanism and control program.
The nominal service conditions include an ambient temperature of -25ºC+40ºC, an ambient relative humidity of 90%, and altitude of 2000m and protection degree of IP65.



Main technology data

The typical usage of travel switch is to control electrical magnent of AC or DC
Control capacity                                    AC-15                                     DC-13
Rated insulation voltageRated insulation currentRated insulation voltageRated insulation current
380V0.8A220V0.15A
220V1.4A110V0.5A
110V2.8A

Rated valueRated insulation voltage Ui=380V conventional enclosed heating current Ith2=10A
Protection for short-circutRated fuse current 1000A RL1-15/10
electricalElectrical life of AC one million and half times,Electrical life of DC three hundred
operation frequencyDC2400 times/hour,AC 1200 times/hour
mechanicalLXK3-20S.H/H1.H2.H3,LXK3-20S.H/W 600 million times  Other specification 1000 million times
Repetition precisionThe difference between the maximaum(or the minimum) and the means is n more than 0.5mm in ten times of actions
Protection degree of enclosureIP65 GB4208-84
Vibration resistanceFrenquency:10-55HZ
Accelerated speed:10g(90M/S)
Amplitude 0.75mm


Type

Action travel

Difference travel

Full travel

Action force

Resilience

Max operation force

Relief force

LXK3-20S H/Z

1.75 -2mm

≤ 1.2mm

≥ 6mm

1± 0.15kg

≥ 0.5kg

3kg


LXK3-20S H/L

LXK3-20S H/B

18° 22°

≤15°

≥60°

1.53± 0.35kg Cro

0.6kg Cro

2.4kg Cro


LXK3-20S

H/T








LXK3-20S H/J

LXK3-20S H/D




1± 0.25kg Cro

0.3kg Cro

2.2kg Cro


LXK3-20S H/H1

70° 80°

40° 60°

90° 5°

2± 0.3kg Cro



2± 0.3kg Cro

LXK3-20S H/H2

LXK3-20S H/H3

LXK3-20S H/W

12° 20°

8°±2°


0.38± 0.08kg Cro

0.15kg Cro



PS:If you can't find the exact type of your product.Please don't rush to go away.Contact me and your questions will be replied ASAP.Thank you for your time.
