Ligao (Zhongshan) Electrical Appliance Co., Ltd. >> Frequency Converter Factory Price 24V to 12V 60 AMP DC Converter Inverter

Frequency Converter Factory Price 24V to 12V 60 AMP DC Converter Inverter

Frequency Converter Factory Price 24V to 12V 60 AMP DC Converter Inverter
Price: US $ 72/Piece
Min Order: 500/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: PV2412-60
Certificate: Ce RoHS
Static Frequency: 50Hz / 60Hz
Warranty: 1 Year

Product Description

Frequency Converter Factory Price 24V to 12V 60 Amp DC converter inverter











SPECIFICATION

Input voltage  20-30V DC
Output voltage12V DC to 13.8V DC
Standby current≤95mA
Output power60A (continuous), 80A (maximum)
Input fuse2*40A, Standard auto blade fuse (external*)
Connection cable8.0mm2 / 900mm
Efficiency85% to 90%
Thermal shutdown65°C+/-5°C
Input polarity reversediode protection
Output shortcircuit protection
Overheatingcircuit protection
Output polarity reversecircuit protection
Operating temperature0~40°C
Storage temperature-15°C~45°C
Operating relative humidity10%RH~102%RH,
Compliant standardsCE, EN61000, 2006/28/EC.
Dimension275*165*79mm
 Net weight1.9kg






Ligao (Zhongshan) Electrical Appliance Co., Ltd has over 20 years of experience in design, manufacturing and marketing of solar supply products and electrical appliances. Conducted by ISO 9001: 2008, with CE, CB, RoHS approvals from SGS, we only provide high quality products.

Our products include:



Covering an area of 40, 000m2, with over 500 workers, our factory is capable of providing OEM and ODM services adequately. With our quality products, competitive prices and excellent services, we win trusts from our clients from the EU, the US, the Middle East, Africa, Asia, and South America. To learn more about us, contact us now.
