Name: FTTH 1*4 PLC Splitter Sc/Upc Connector
Brand: all-electronics-online.com
SKU: 691797272
Availability: InStock
Rating: 4.5 (128 reviews)

Price:	US $ 9.8/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	1*4 PLC Splitter
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Place Of Origin:	Zhejiang, China (Mainland)
Brand Name:	Softel/OEM
Model Number:	FTTH PLC
Name:	FTTH Mini PLC Splitter
FTTH Pon Splitter Application:	FTTH, Fttp, Fttn, Fttc
Operation Wavelength:	1260nm--1650nm
Insertion Loss:	<17.2dB
Storage Temperature:	-40~85
Type:	Optical Splitter
Wiring Devices:	Optical Splitter
Transmission Medium:	Single-Mode
Structure:	SC
Number Of Cores:	Single-Core
Ferrule Endface:	APC
Connector Type:	Sc, FC, St, LC
Brand:	Softel

Product Description

SC/UPC Blue Connector For 1x4 Optical Splitter

Application:
1) FTTX (FTTP, FTTH, FTTN, FTTC)
2) Passive Optical Networks (PON)
3) Local Area Networks (LAN)
4) CATV Systems
5) Test Equipment

Certificate:
The PLC splitter family(1x4, 1x8, 1x16, 1x32, 2x16, 2x32 1x64 ) has two classes-grade and S-grade, with specifications that are tailored
For different applications and markets. All splitter's feature guaranteed performance specifications and high reliability that surpass Telcordia requirements.
Low Insertion loss
Low PDL
High return loss
Uniform power splitting
Compact design
Wide operating wavelength
Wide operating temperature
Excellent Environmental&Mechanical Stability
Qualified Under Telcordia GR-1221 and GR-1209

Parameters			1x4	1x8	1x16	1x32	1x64
1	Operating Wavelength(nm)		1260-1650
2	Insertion Loss (dB)	Max(S/P)	7.4/7.2	10.7/10.5	13.7/13.5	16.9/16.5	21
3	Loss Uniformity (dB)	Max	0.6	0.8	1.2	1.7	2.5
4	Return Loss (dB)	Min(S/P)	50/55	50/55	50/55	50/55	50
5	PDL (dB)	Max	0.2	0.3	0.3	0.3	0.4
6	Directivity (dB)	Min	55	55	55	55	55
7	Pigtail Length(m)		1.2(±0.1) or customer specified
8	Fiber Type		SMF -28e or customer specified
9	Wavelength Dependent Loss(dB)		0.2	0.2	0.3	0.3	0.3
10	Temperature Stability(-40~85)(dB)		0.3	0.3	0.4	0.4	0.4
11	Operating Temperature		-40~85
12	Storage Temperature		-40~85
13	Packaging Size(L x W x H)(mm)		40x4x4	40x4x4

Hangzhou Softel Optic Co., Ltd. (Brand: SOFTEL) was established in 2006, which Located in the HangZhou Hi-Tech Development Zone. Taking advantage of the modern broadcast and optic fiber communication technology, we are specializing in R&D of CATV system equipment, and leading manufacturer of HFC broadband Optic Transmission equipment with strong R&D capability in this field.

We have more than 100 staff in which 10% of senior technicians. It has more than 1, 000 square meters standards production assembling line, we have strict QC procedure, each unit of our products will go through 3 layer QC procedure, material checking before production, stability and performance testing after production, packing checking before delivery.

Currently, we supplying to numerous agents, integrated dealers and equipment producers all over the world, most of our products move to South America, Russia and north European countries.

Through keen international business competition in good faith, all of our staffs feel big accomplishment & work under heavy responsibility. In addition, we are much proud of providing our invaluable customers with our high quality, high reliability, high efficiency, competitive products.
