FTTH Fiber Optic Patch Cord

Name: FTTH Fiber Optic Patch Cord
Brand: all-electronics-online.com
SKU: 748228135
Availability: InStock
Rating: 4.9 (70 reviews)

Price:	US $ 0.5-3.99/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	DTFTTH Patch cord
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Insert Loss:	< 0.20db
Return Loss:	> 50db
Length:	Customized Lengths 0.5m-50m
Full Types Of Optical Patch Cords:	Sc, LC, FC,St, E2000, Mu, MPO......
Application:	Communication
Type:	Single-mode Fiber
Certification:	ISO9001
Brand:	Datolink
Sheath Material:	PVC or Lszh
Connection Structure:	FTTH

Product Description

Products detail:

Fiber Optic FTTH Patch Cord
Specifications
Fiber Optic FTTH Patch Cord
Simplex, Single-mode
0.9/2.0/3.0mm
Customized lengths (1m/2m/3m...)
High return loss

Features:
Low insertion loss(≤ 0.20dB)and high return loss(≥ 55 dB)
Free-floating ceramic ferrule
UL-rated plastic housing and boot
Boots in a variety of colors
High precision alignment connector

Applications:
Local Area Networks (LANs) and Wide Area Networks (WANs)
Fiber Optic CATV, FTTH, FTTB, FTTP etc
Fiber Optic telecommunication systems
Transmission Mode (ATM)
Fiber Optic Backbone
Military Instrumentation

Packaging
One piece per PE bag with stick label (we could add customer's logo in the label. )
OEM
Standard and customized OEM products from small to large quantity are welcome.
Compliance with global environmental industry with RoHS and SGS standards.
All products are 100% fully tested by our technical expertise.

Shipping
Door to Door: By express (such as DHL, UPS, TNT, FedEx, Aramex etc. )
Airport to Airport: By air
Seaport to Seaport: By sea (our location Shenzhen is a seaport. )

Specifications
	Single mode	Multimode
Insert Loss	≤0.20dB	≤0.25dB
Return Loss	≥50 dB (PC)
	≥55 dB (UPC)
	≥65 dB (APC)
Durability	<0.20 dB typical change, 1000 mating
Operating Temperature	From -40 to + 80°C	From -40 to + 80°C
Ferrule Hole Sizes	125.0+1/-0μm, Concentricity: ≤1.0μm	125μm, Concentricity: 1≤3μm
	125.5+1/-0μm, Concentricity: ≤1.0μm	127μm, Concentricity: 1≤3μm
	126.0+1/-0μm, Concentricity: ≤1.0μm	128μm, Concentricity: 1≤3μm

Shenzhen Datolink Communication Technology Co., Ltd. Was founded in the January of 2007 by several engineers, who have had many years of working experience in fiber optical as well as in structured cabling industry. Datolink is a high technology oriented company with fiber optical products and structured wiring. We are dedicated to the design, manufacture and sales, meanwhile, we can provide customers with complete cabling solutions in installation and maintenance.

The company has a strict and comprehensive system of quality control and approved the standard ISO9001: 2000. Is well connected with raw materials providers and factories worldwidely, to offer customers a broad line of products with competitive prices and very soon time of delivery.

Our products have been exported to over 20 countries and regions such as Europe, Middle East, Southeast Asia, Latin America, etc. Datolink Ltd is committed to offer the partners high quality products and professional services, we look forward for the successful development with mutual-benefits, for casting the future of fiber optical and structured cabling!
