Full Equipped Optical Green Laser Marking Machine for ABS PVC

Name: Full Equipped Optical Green Laser Marking Machine for ABS PVC
Brand: all-electronics-online.com
SKU: 793683095
Availability: InStock
Rating: 4.9 (122 reviews)

Price:	US $ 5000-9000/Set
Min Order:	1/Set
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	CKD-GMLA-3
Function:	Marking, Engraving
Material:	Plastic and Other Non-Metal
Rotary Marking:	Add Rotary

Product Description

Full Equipped Optical Green Laser Marking Machine

CKD-GMLA-3

Application

Materials: Marking on plastic, ABS, PVC, oil paint and so on.

Field: Electronic components, mechanical parts, instrument, automobile parts, clothing, craft, cosmetics, food, stationery, brand board, products packing box, color paper, all kinds of spray paint products, cigarettes, arts, crafts and other daily necessities, etc.

Advantages
1, 532nm wavelength suitable for sensitive materials, 5ns short pulse duration, short acting time, low heat effect.
2, Smaller spot diameter, more concentrated energy, high electro-optical conversion efficiency, and 3, good beam quality.
4, Comprehensive function, high cost performance.
5, Convenient marking control, stable and reliable.
6, Compatible for all formats from CorelDraw, Photoshop, AutoCAD, etc.

Parameters	Unit	Data	Data
Type		CKD-UMLA-1.5	CKD-UMLA-3
Laser source average output power	W	1.5	3
Laser Type		Green laser	Green laser
Laser Wavelength	nm	532±1	532±1
Optional Marking Area	mm	5050/100100/150*150	5050/100100/150*150
Marking Speed	mm/s	≤15000	≤15000
Minimum Line Width	mm	0.01	0.01
Minimum Character	mm	0.1	0.1
Controller (Software - EzCad)		JCZ	JCZ
Life-span of Laser Module	h	20000	20000
Power stability		(rms, over 8 hours) <1%	(rms, over 8 hours) <1%
Beam divergence, full angle	mrad	<2	<2
Beam diameter at aperture	mm	6	6
Beam height from base plate	mm	16.5	16.5
Transverse mode		TEM00	TEM00
Peak power	KW	15	30
System Operation Environment		Windows XP / Windows 7 / Windows 8	Windows XP / Windows 7 / Windows 8
Cooling Mode		Air cooling	Air cooling
Temperature of Operation Environment	ºC	10~35	10~35
Voltage		90-240V/50-60Hz/2KVA	90-240V/50-60Hz/2KVA
Pulse repetition rate	KHz	20	20
Computer Requested		with	with
Dimension (LWH)	mm	7977501440	7977501440
Weight	Kg	70	70

Samples

Certifications

Company Information

CKD LASER Co., Ltd is located in Shenzhen, one of the most energetic and creative city in China. We focus on laser from 2007 and start to exploit overseas from 2015.

CKD LASER is a progressive company and has a strong design ability, quickly reactivity ability based on the newest market trend. We have a professional, experience and energetic technical team, so that we always can supply the suitable laser solution to customers. We are in strict accordance with CE security standard and other world product safety requirements, pursue high-tech, high quality, and high customer satisfaction products, to seek long-term cooperation and common development customers all over the world.

Company concept: All participate in and strive together to creative our future

Quality policy: Based on customer satisfaction

Armed high quality by high-tech

Welcome new customers' attention and thank old customers' support! We will as always provide you the higher performance, cost-effective goods and support you the excellent service timely.
