| Prod Model: |
S1100E |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: |
Mc |
| Model Number: |
S1100e |
| Output Power: |
0.4-475kw |
| Input Voltage: |
200-240V, 380-460V |
| Output Voltage: |
200-240V, 380-460V |
| Output Frequency: |
0-400Hz |
| Control: |
V/F Control |
| MOQ: |
1 PC |
| Certificate: |
Ce |
| Payment: |
T/T, Western Union |
| Application: |
High-performance Transducer |
| Output Type: |
Triple |
| Principle Of Work: |
V/F Control Transducer |
| Switch Mode: |
PWM Control |
| Main Circuit Type: |
Current |
| Brand: |
Machtric |
Product Description
Specifications:
1) Rated voltage: 220V, single & 3 phases, 440V, 3 phases
2) Power range: 0.75 ~ 315kW
3) Output frequency: 1.0 ~ 400Hz
Feature:
1. High performance, superior performance,
2. Low noise,
3. Mini size,
4. Adopting the latest generation IGBT technology
S1100 E Series-Universal
Purpose Inverter
High-performance, multifunctional
Universal inverter
The hole size of the tray for the operating panel
5.5KW(included) above: 141.5mmx79.5mm
3.7KW(included) below: 99.5mmx56mm
Target market of S1100 E series Inverter
Air conditioning, greenhouse, cold room
Blowing machine, water pump, air compressor
Conveyor, conveyor beit, cold storage facilities
CNC lathe, grinder, drill press, vertical machining centers, saws bed
|
Items |
S1100 E |
Power
Supply |
Rated voltage, Frequency |
Single phase/Three phase 220V 50/60Hz Single-phase 220V 50/60Hz |
Voltage Range |
220V: 170V~240V; 220V: 170V~240V |
Output |
Voltage Range |
220V: 0~220V; 220V: 0~240V |
Frequency Range |
0.10`400.00Hz |
Control method |
V/F control, Space vector control. |
Indication |
Operating status/Alarm definition/interactive guidance: eg, frequency setting, the output frequency/current, DC bus voltage, the temperature and so on. |
Control Specifications |
Output Frequency Range |
0.10Hz~400.00Hz |
Frequency Setting Resolution |
Digital input: 0.01Hz, analog input: 0.1% of maximum output frequency |
Output Frequency Accuracy |
0.01Hz |
V/F Control |
Setting V/F curve to satisfy various load requirements |
Torque Control |
Auto increase: auto raise torque by loading condition; manual increase; enable to set0.0~20.0% of raising torque |
Multifunctional Input
Terminal |
Eight multi-function input terminals, realizing functions including fifteen section speed control, program running, four-section acceleration/deceleration speed switch, UP/DOWN function and emergency stop and other functions |
Multifunctional Output
Terminal |
3 multi-function output terminals for displaying of running, zero speed, counter, external abnormity, program operation and other information and warnings |
Acceleration/deceleration time Setting |
0~-6000s acceleration/deceleration time can be set individually |
Other Functions |
PID Control |
Built-in PID control |
RS485 |
Standard RS485 communication function(MODBUS) |
Frequency Setting |
Analog input: 0 to 10V, , 0 to 20mA can be selected;
Digital input: Input using the setting dial of the operation panel or RS485 or UP/DOWN |
Multi-speed |
Eight multifunction input terminals, 15section speed can be set |
Automatic voltage regulation |
Automatic voltage regulation function can be selected |
Counter |
Built - in 2group of counters |
Protection/
Warning Function |
Overload |
150%, 60 second(Constant torque); 120%. 60 second (variable torque) |
Over Voltage |
Over voltage protection can be set |
Under Voltage |
Under voltage protection can be set |
Other Protections |
Overheat, short circuit, over current, and parameter lock and so on |
Environment |
Ambient Temperature |
-10 ° C to 40 ° C (non-freezing) |
Ambient Humidity |
Max. 95%(non-condensing) |
Altitude |
Lower than 1000m |
Vibration |
Max. 0.5G |
Structure |
Cooling Mode |
Forced air cooling |
Protective Structure |
IP20 |
Installation |
Mode |
Below 90KW: Wall Mounted; 110~200KW: Wall Mounted or in Cabinet; Above 220KW: in Cabinet |
FAQ
| Questions | Answers |
| What is your payment ? | Our payment is by T/T. Western Union. L/C and Money. |
| Is there a discount on the price of your product? | It depends the quantity of order. |
| Is same quality between the sample and big order? | Our products are always as good as the samples we send, I can promise there will be no debasement of quality. |
| Is the price for FOB? | Yes. |
| How much is your minimum order quantity? | 1 pcs or unit. |
| How do we send goods to customer? | Shipping by Express: DHL, TNT, UPS, Fedex, by Sea and by Air; Or customer forwarder are accepted. |
