| Prod Model: |
EP2000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Protection: |
Discharge, Overcharge, Overload |
| Audible Noise: |
60dB Max |
| Max Charger Current: |
75A |
| Transfomer: |
Max10ms |
| DC Voltage: |
12V 24V 48V |
| Power: |
1000W-12000W |
| Packaging: |
Carton and Wooden |
| Waveform: |
Sine Wave |
| Monitoring Software: |
RS232/Remote Control Board |
| Generator Compatible: |
Yes |
Product Description
Main features:
1. Pure sine wave power inverter DC to AC 300W-3000W
2. With LCD/LED display
3. Pure sine wave
4.150% overload capacity
Details:
1. Pure sine-wave output, can be used with diffent domestic appiance TV, refrigerator, fan, air conditioner induvtion cooker, micro-wave oven etc
2. Superior performance from CPU control technology
3. Wide range of input voltage, accurate output, AVR function
4. Inner-equipped protection for over-load, short-circuit, over-voltage, low-voltage over-heating etc.
5. Easy to check with UPS condition with consice LED indication that can be upgraded
To LCD
6. Generator compatibly and external battery connection achievable
7. Intelligent battery management with protection against over-charged and over-discharged etc.
The Inverter is is devised to work in regions or countries of continuous AC power problems, and is also a truly revolutionary UPS. This series are a kind of industrial applications that the typical Inverter will not be satisfied and using a generator is not practical. The units output pure sine wave, surge suppression, AC voltage regulation. The external batteries can be quickly recharged by a powerful battery. Load levels, battery levels and status of operation of the unit can be visioned on the LED display. This design is the best choice for telecom, security and industrial PC applications.
| MODEL | | PT300 | PT600 | PT1200 | PT1500 | PT3000 |
| CAPACITY | W | 500VA(300W) | 1KVA(600W) | 2KVA(1200W) | 2.5KVA(1500W) | 5KVA (3000W) |
| INPUT | Phase | Single |
| Voltage | 100/110/127/220/230(+25%,-25%) |
| Frequency | 60/50+/-10% |
| OUTPUT | Phase | Single |
| Voltage range(VAC) | 100/110/127/220/230+/-5% |
| Frequency | Commercial power supply shared frequency with the commercial inversion state:60/50+/-0.5 |
| Waveform | Sine wave |
| Power Factor | P.F. | 0.6 | 0.6 | 0.6 |
| BATTERY | DC Voltage | DC12V | DC12V | DC24V | DC48V | DC48V |
| Back up Time | Standard model: (halfload)>/=8min |
| Recharge current | Long back up model: 15A max, standard model: 3A max |
| TRANSFER TIME | Typical | Typical: 5ms (Including detection time) |
| Display | LCD/LED | Optional |
| PROTECTION | Full Protection | Discharge, overcharge, and overload protection |
| PHYSICAL | Dimension, DXWXH (mm) |
375*130*190 | 452*192*338 | 452*192*338 |
| Out packing Size, DXWXH (mm) | 495*490*320(2pcs/ctn) | 584*335*495(1pcs/ctn) | 584*335*495(1pcs/ctn) |
| Net Weight (kgs) | 12 | 23 | 27 | 33.7 |
| ENVIRONMENT | Operating Environment | 0~40 Degrees Centigrade, 0~90% relative humidity (non-condensing) |
| Noise Level | Less than 40dB |
| INTERFACE | Smart RS-232 | Support Windows family, Linux, Compaq True64, |
| USB Option | N / A |
