Good Professional Assembled Laser Cutter Carbon Fiber Laser Cutting Machine

Prod Model:	985
Model No.:	Dpl-3015-1000I
Type For Cutting Machine:	Laser Cutting Machine
Automation:	Automatic
Type:	Laser Cutting Machine
Laser Wavelength:	1070nm
Applicated:	Machinery & Hardware
Certification:	SGS, Ce, ISO 9001:2000
Condition:	New
Medium Of Laser:	Semiconductor Pump Continuous Ytterbium Doped Fibe
Export Markets:	Global

Product Description

Good price Professional assembled laser cutter carbon fiber laser cutting machine






Advantage Features:

1. Cost saving on power consumption/ only 20-30% of co2 laser cutting machine
2. Higher cutting speed 120m/min and Imported servo motor and gearing system ensure precision cutting
3. Easy of operation
4. Error detection, diagnosis & solution
5. Scan cutting: Short distance cutting without head lifting
6. Automatic search edge function: if work piece put slanting, machine can auto detect it and automatic adjust cutting, so less waste of material and no need to move the metal sheet
7. Memory cutting: Once power off suddenly, the software has memory of cut stop point, when power on, the machine will continue cutting from the break point.
8. Adopts Proportional Valve: Control the air pressure automatically replace of manually, save much time.
9. Safety Features : Pause / Emergency Stop (can we pause or stop machine during cutting )
10. Stable working table: DAPENG cutting bed around 4.5 tons in weight, Dual drive, aging treatment, stress relief test, make sure long time lasting without changing shape.
11.

Main Components list:


No.	Description	Made of origin place and Manufacturer
1	Fiber Laser source	IPG 1000W from Germany
2	Laser Head	Technology and components from Germany, assembled in China
3	Guide Rails	Hiwin from Taiwan
4	Rack & Pinion	YYC from Taiwan
5	Speed Reducer	Shimpo from Japan
6	Servo Motor & Driver	Schneider from France
7	Proportional	Aventics from Germany
8	Pneumatic Components	Airtac from Taiwan
9	Circuit Breaker	Schneider from France
10	Relay	Omron from Janpan
11	Chiller	China Dongluyang
12	Cutting System	China Cypcut
13	Bed	DAPENG 4500kg
14	Cable Carrier	IGUS




Specifications:

Model	DPE-F1000-3015IP
Laser power	1000W
Cutting area(mm)(L×W)	3000mm×1500mm
Max cutting speed(m/min)	120 m/min
Max Accelerated	1.5G
Positioning accuracy	±0.03mmmm
Reliability accuracy	±0.02mm
Min line width	0.15mm
Max Cutting depth (Mild Steel)	12mm
Stainless Steel O2	8mm
Stainless Steel N2	5mm
Driving Way	Imported servo motor
Transmission Way	Imported gear rack & pinion double driver
Electrical Requirements	380V/50Hz.60Amp
Power Consumption	12KW
Work Piece Weight	800kg
Weight	4500kg
Outline size(mm)	4800mm×2700mm×1900mm  (L×W×H)



Applicable Materials:
Stainless steel, Mild steel, alloy steel, silicon steel, spring steel, aluminum, aluminum alloy, galvanized sheet and other metal pipes and tubes.

 Cutting Process Parameters:

IPG 1000W(Germany)
Materials	Thickness(mm)	Cutting speed (m/min)	Gas
Stainless steel	0.5	60	N2
	0.8	30	N2
	1.2	15	N2
	2	5.1	N2
	3	2.4	N2
	3.5	1.2	N2
	4.5	0.6	N2
Mild steel	0.5	15.6	O2
	0.8	9.6	O2
	1.2	7.8	O2
	2	6	O2
	4.5	1.8	O2
	5.5	1.5	O2
	7.7	1.08	O2
	9.2	0.78	O2
Aluminium	3	3	O2
	2	6	O2
	1	30	O2
	1	12	N2
Galvanized Steel	1	15	N2
	2	4.2	N2
	3	1.5	N2
Brass	1	15	N2
	1.5	7.2	N2
	2	4.2	N2
	2	7.2	O2

Cutting Examples:








Shenzhen DAPENGLaser Technology Co., Ltd.

Headquartered in Shenzhen, the company operating layout covering the East Coast Main industrial provinces and cities: Guangzhou, Foshan, Zhongshan, Jieyang), Fujian (Xiamen), Wenzhou, Zhejiang, Ningbo), Jiangsu (Wuxi), Shandong (Qingdao) and the Indian agent, vertical integration of upstream and downstream production process, diversification of laser equipment, products, production elasticity, effectively shortening the supply chain and meet the needs of customers purchasing, reduce time and cost of procurement.

Dapeng laser Dedicated in R & D, manufacturing, sales of industrial laser equipment, the main products of the company including laser marking machine series, laser welding machine, laser cutting machine series, specially used in the industry and automatic customization of laser equipment, at the same time, it provides parts of lasers and related equipment for the Chinese and global laser industry manufacturers. In selling all kinds of laser equipment more than 4000 units, is the domestic well-known from research and development, raw material procurement, production, distribution and after-sales and a series of full set of professional service of laser equipment manufacturers and sales of its products covers mainland China, Taiwan, Southeast Asia, India, Japan, Korea, Europe and the United States, and actively expand in Eastern Europe, the Middle East, Eurus, South America and other emerging markets.

Dapeng laser is committed to provide stability is the highest and most of the price ratio of industrial laser equipment for the customer, Guangdong Dapeng LNG Company products both in performance, stability, the warranty period and price relative to the companies in the same industry products has incomparable advantages. Is one of the leading brands in China's standard laser marking machine, welding machine and cutting machine. 2005, officially entered the laser equipment industry, after 10 years of hard work to cultivate, Dapeng laser has been among the well-known industrial laser equipment manufacturers, the company has experience of 10 years of professional R & D design team, for the industry to develop customized non-standard automation laser equipment. We are committed to become the field of industrial laser equipment total solution provider, for customers to provide high-quality, high stability, high price of industrial laser equipment and a full range of technology support service.

Our professional services:

1. Provide service from a full package of materials and equipment research and development, proofing, automation of laser equipment design.

2. the perfect pre-sale, sale and customer service service system.

3.Customer satisfaction guarantee commitment.


DAPENGLaser Cutting Department

The cutting department built bused on our R&D Engineer team in 2015,and we have provide over 200 Laser cutting machines to our customers and our equipments and technical service are proved by our customers.

The DAPENGLaser cutting machine are widely used in crafts, electronics, toys and other industries, used in sheet metal, metal products, jewelry, nameplate, advertising, packaging steel structure, precision machinery, auto parts, glasses, and other industries. For the stainless steel plate, iron plate, aluminum, ceramics, silicon and diamond cutting. Can also be metal, a variety of non-metallic materials, pipe cutting

Sample marking







Shenzhen Dapeng Laser Technology Co., Ltd. was founded in 2008, is a research and development, manufacturing, sales and service in one of the laser equipment of high-tech enterprises, is committed to technology research and development of laser, laser equipment design and development, production, technical support and consulting services.



The company's main products include: laser cutting machine, laser welding machine, laser marking machine, laser equipment and automation industry, used in electronics, IC chip, electrical appliances, lighting, jewelry, hardware tools, sanitary ware, instrumentation, auto accessories, mobile phone parts, molds, precision machinery medical devices, IT, digital, metal shell, military aviation parts, leather clothing, crafts gifts, advertising decoration, cooking utensils, kitchenware model, and other industries.

Dapeng laser product quality is stable and reliable, has a professional R & D team, the pursuit of excellent quality at the same time, Dapeng laser also provides customers with timely, good pre-sale, sale, customer service service and excellent cost-effective products. Dapeng laser through the implementation of "to help customers succeed, create value model, build industrial laser equipment industry high-end service brand" business philosophy, won the trust of customers and praise. Customers are distributed all over the country and overseas, in 2016 sales of laser equipment more than 5000 sets.



The company has established a perfect production and sales and customer service service system in Shenzhen, Wenzhou, Kunshan, Xiamen has a production base in Dongguan, a large laser cutting machine production base, and has offices in the major industrial city and regional offices have equipment display, process proofing, sales and customer service in technical service personnel, to provide customers with timely, good pre-sale, sale, customer service support and service.



Dapeng people know that quality and service is the fundamental survival, innovation is the foundation of the company's long-term development, to help customers create value, and strive to build the laser equipment industry well-known brands.
