| Prod Model: |
Car GPS Tracking System Tk103 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Network: |
GSM/GPRS |
| Warranty Time: |
1 Year |
| Size: |
110mm*82mm*28mm |
| Weight: |
120g |
| Functions For Car Tracking: |
Cut Car Engine&Door Lock Sytem, Dual Fuel Check |
| Disable The Vehicle Remotely: |
Remotely Cut Car Engine |
| Main Functions For Vehicle: |
Acc, Door, Sensor, Overspeed Alarm |
| GSM Frequence: |
850/900/1800/1900MHz or 900/1800/1900MHz |
| Tracking Solutions: |
SMS, GPRS Web Based Platform, Android Ios APP |
| GPRS Communicate Protocol: |
TCP and UDP Protocol |
| Type: |
GPS Tracker |
| Use: |
Automotive |
| Operating Principle: |
GPS Satellite Positioning and Data Transmit by GSM |
| Port Number: |
GPS Position and GSM Transmit Data |
| Model: |
Car GPS GPRS GSM Tracker Tk103 |
| Screen Size: |
No Screen |
| Chip: |
No |
| Brand: |
Baanool GPS Tracker |
| Certification: |
ISO9001 |
Product Description
gprs gsm car alarm gps tracking system TK103
1. SOS emergency/alarm function
2. Tracking via GSM or GPRS
3. Low price, fast deliver
4. Power and oil cutting off system
Advantages:
The GPS devices support phone tracking and 8 languages website tracking. (English, Spanish, Portuguese, Arabic, Thai language, Italian, German, Chinese)
1. Four types Tracking way:
A>: SMS + Map software;
B>: PDA Cell Phone;
C>: Real time tracking, and track via your computer;
D>: Simple & useful real time tracking via our website.
2. Newest update functions:
-Support 4GB SD Card, old version, do not have this function.
-Less GPRS traffic function, old version, do not have this function.
-Configure by PC, not just by cellphone like old Tk103.
-Support TCP and UDP protocol.
Specifications:
Contentspecifications
DIM. 54*62*26mm
Weight120g
NetworkGSM/GPRS
Band850/900/1800/1900MHz
GSM/GPRS ModuleSimcom300d or Simcom340d
GPS ChipSIRF3 chip
GPS Sensitivity-159dBm
GPS Accuracy5m
GPS Start timeCold status 45s
Warm status 35s
Hot status 1s
Voltage of car power system12 V -24V
Backup batteryChargeable changeable 3.7V 800mAh Li-ion battery
Storage Temp. -40° C to +85° C
Operation Temp. -20° C to +65° C
Humidity5%--95% non-condensing
FunctionsTracking; Monitor; Geo-fence; Movement alert; Overspeed alert; SOS Button; Low battery alert; Hidden number tracking; Power off alarm; Send SMS cut off/resume the oil and power system, arm, door alarm, sensor alarm, ACC alarm; Supoort 4G SD card; Support TCP and UDP protocol
Warranty12 months Warranty
Functions:
Support non-server based location
Location memorization
Auto location report
Authorize/delete the tracking phone number
Covert alert & voice surveillance
Geo-Fence: Alert in case of breaching the predefined district
Movement alert: Alert in case of movement
Speed alert: Alert in case of excess of the pre-definded speed
Power alert: Alert when device is being switched off
Remote Engine-stop and Resume
Door alarm
ACC alarm
Low batttery alarm
Check the vehicle status
Optional functions:
Quiver alarm
vehicle GPS Tracker TK103A/B specification
| Content | specifications |
| DIM. | 83*54*26mm |
| Weight | 120g |
| Network | GSM/GPRS |
| Band | 850/900/1800/1900Mhz |
| GPS Sensitivity | -159dBm |
| GPS Accuracy | 5m |
| GPS Start time | Cold status 45s
Warm status 35s
Hot status 1s |
| Voltage | 12 V -24V
|
| Backup battery | Chargeable 3.7V500mAh Polymer Li-Battery |
| Storage Temp. | -40°C to +85°C |
| Operation Temp. | -20°C to +65°C |
| Humidity | 5%--95% non-condensing |
More details including user manual and photos etc will be sent after receive your inquiry -2016/7/11
Shenzhen Coban Electronics Co., Ltd is a private export-oriented enterprise founded in 1999, 90% of the products are exported, and we have many years of research and development, production and management experience in automotive electronics, security products, wireless communications terminal equipment, and other fields.
As a high-tech enterprises, we have a strict management system, and have obtained the authentication of CCC, CE, FCC and UL ISO9001, etc. So far, our products have been well marketed in 107 countries and regions in the world. Our company has set up research and development centers, including GPS R & D department, GSM R & D department and system integration Department. All the products are developed independtly and obtained a number of national patents. So the professional R D team, efficient production team provide good foundation with high-quality products. Quality has always been part of the company's most stressed. Before all the products entering the market, they have been tested rigorously such as high and low temperature aging test, vibration test, the noise tests, audio and video indicators decomposition tests.
Our company specialized in GPS tracker, car anti-theft alarm system.
Except the advantage of abundant in human resources, since we count on long standing business relationships, we deserves wide range of cooperation with the well-known Chinese and foreign high-tech companies and service in the long term. In order to meet the developing of the markt, our aim is to transform the latest and the best research fruit into productive quickly, develope science and technology, serve the society.
