| Prod Model: |
TK121 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model Number: |
Tk121 |
| Color: |
Black |
| GSM Frequency: |
850/900/1800/1900MHz |
| Working Voltage: |
12VDC/24VDC/36VDC |
Product Description
People have started using gps tracking solutions for variety of purposes and that's why Eelink brings you some of the best gps tracking solutions. Affordable gps tracking solutions available at Eelink can definitely give you lot of advantages which should make you check out these gps tracking solutions. You will be able to understand that why people are investing money and purchasing gps tracking solutions after reading this article which mentions the reasons making people go for gps tracking solutions.
Specifications
*Realtime vehicle tracking system
*Fleet Management Solution
*Multiple kinds of Alarm
*OTA software update
Applications
Logistics Fleet Monitoring & Management
Concrete Mixing Fleet Monitoring & Management
Reefer Fleet Monitoring & Management
Taxi Fleet Monitoring & Management
Construction Machineries Monitoring & Management
Using TK116 GPS tracker, we can position, monitor and control the vehicle on the position server via GPRS, GPS and Internet. It can help customers to manage transparently, reduce cost, maintain security and raise efficiency. Now it is widely used in business traffic, logistics distribution, automobile lease, intelligent transportation, shipping market, army and police, rescuing, Safety Supervision, Intelligent city
Tk116 provide complete tracking system for you
Product Features
*Supports quad bands, i. E. 850/900/1800/1900MHz, worldwide used.
*Wide Input Voltage: 6-36V DC.
*GPS + GSM (LBS) Tracking
*GPS precise positioning with A-GPS and feedback position via GPRS at setting times
*Tracks real-time and playback
*Web browser platform, Smart phone app platform and SMS query.
*Built-in battery, Power disconnect alarm & Low battery alarm.
*Supports multiple alarm, acceleration sensor can be added (B models, optional component), so as increase vibration, collision and falling alarm.
*Supports ACC status checking and vehicle status notifying.
*Use relay to remotely control the vehicle...
*Use SOS button for SOS call.
*Uses external microphone to monitor remotely.
*Multiple protocol support, OTA upgrade program.
*Mini size, easy to hide and install
Main Function
GPS OK
AGPS OK
Remote cut oil/engine OK
Monitor/listen OK
ACC OK
OBD diagnostics NO
Built-in battery OK
Pedometer NO
Power failure Alarm OK
Low power Alarm OK
SOS Alarm OK
Speed Alarm OK
Shift Alarm OK
Collision Alarm OPTIONAL
Falling Alarm OPTIONAL
Vibration Alarm OPTIONAL
Geo-fencing Alarm OK
Platform
You can choose Keelin terminal monitoring platform or not. It is designed by EELINK, we can position, playback the cars' track, listen and cut off oil of car on the platform server.
| Brand | Eelink |
| Model | TK116 |
| Quantity | 1 piece(s) |
| Color | Black |
| Material | ABS |
| Network | GSM |
| Band | 850\900\1800\1900 MHz |
| SIM Card Qty. | one SIM |
| Emergency Phone Number Qty. | 3 |
| Tracking Information Method | Monitoring and controlling platform |
| Power Supply | DC 6~36V |
| GPS Chip | SIRF |
| GPS Sensitivity | -163 dB |
| GPS Channel | 20 |
| Position Accuracy | 10 m |
| Altitude Limit | 18000 m |
| Hot Start | 3 seconds |
| Warm Start | 15 seconds |
| Cold Start | 60 seconds |
| SOS | Yes |
| Geo-fence | Yes |
| Vibrating Alerts | Yes |
| Remote Monitoring | Yes |
| Engine Cut Off | Yes |
| Realtime Monitoring | Yes |
| Track Playback | Yes |
| ACC Anti-Theft | Yes |
| Overspeed Alerts | Yes |
| Low Battery Alerts | Yes |
| GPS Blind Area Alarm | Yes |
| Voice Call | No |
| Waterproof Function | Yes |
| Waterproof Rate | Daily user water resistant |
| Working Temperature | -35ºC~75ºC |
| Working Humidity | 5%~95% |
| Manufacturer's Warranty | 12 Months excluding physical damages (see specifications for terms and details) |
| Certification | CE |
