| Prod Model: |
coban tk103a |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dim: |
83*54*26mm |
| Weight: |
120g |
| Network: |
GSM/GPRS |
| Band: |
850/900/1800/1900MHz |
| GPS Sensitivity: |
-159dBm |
| GPS Accuracy: |
5m |
| Voltage: |
12 V -24V |
| Backup Battery: |
500 mAh |
| Warranty: |
One Year |
| Type: |
GPS Tracker |
| Use: |
Automotive |
| Port Number: |
Multichannel |
| Chip: |
SiRF |
| Screen Size: |
No Screen |
| Operating Principle: |
Tracking |
| Model: |
Tk103 |
| Brand: |
Coban/Neutral |
Product Description
Product Description
It is based on GSM/GPRS(850/900/1800/1900MHZ) and GPS satillite global position system .
1. Summary
This tracker is a new product based on the GSM / GPRS network and GPS satellite positioning system, which set multiple functions of security, positioning, monitoring surveillance, emergency alarms and tracking in its entirety. It can track and monitor remote target by SMS or intercet.
2. Main Function Description
*Single Locating
•Auto track continuously
•Track with limited times upon time interval
•Track with unlimited times upon time interval
•Smart track upon time and distance interval
•Automatic update positions of vehicle turns
•GPS drift suppression
•Absolute street address by SMS
•Location based service (LBS)
•Monitor(voice surveillance)
•Data logging
•Data Load
•Forward the third parties' message
•Charges Inquiry
•Low battery alarm
•Power off alarm
•GPS blind Spot alert
•SOS
•Geo-fence
•Multi-area management
•Movement alarm
•Over speed alarm
•Accident alarm (Option)
•ACC working alarm
•Fuel alarm;Fuel level measurement
•Cut off the Oil and Power System remotely
•Arm
•Disarm
•Alarms under Arm State
•Door alarm
•3-aixs accelaration sensor
•ACC alarm
•Silent Mode
•Alarm without GSM network service
•Check the Vehicle State
•Reset Hardware
•Sleep Mode
•Terminal (local) Time Setting
•TCP/UDP switch
•Configure parameters by USB
•GPRS Setting
•Less GPRS traffic
•Modes Switch between SMS and GPRS
•Set up monitor center number
Specification:
| Content | specifications |
| DIM. | 83*54*26mm |
| Weight | 120g |
| Network | GSM/GPRS |
| Band | 850/900/1800/1900Mhz |
| GPS Sensitivity | -159dBm |
| GPS Accuracy | 5m |
| GPS Start time | Cold status 45s
Warm status 35s
Hot status 1s |
| Voltage of car power system | 12 V -24V
|
| Backup battery | Chargeable 3.7V500mAh Polymer Li-Battery |
| Storage Temp. | -40°C to +85°C |
| Operation Temp. | -20°C to +65°C |
| Humidity | 5%--95% non-condensing
|
Multiple Tracking Ways:
*Calling the gps tracker via your mobile phone,it will reply a SMS including longitude and latitude and a google map link,open this link,you can see the location on the google map.
*Real track by our own developing ios app and andriod app.
*Web based online tracking system our server www.gpstrackerxy.com. (demo id:demo,password:8888)
Shenzhen Coban Electronics Co., Ltd is a private export-oriented enterprise founded in 1999, 90% of the products are exported, and we have many years of research and development, production and management experience in automotive electronics, security products, wireless communications terminal equipment, and other fields.
As a high-tech enterprises, we have a strict management system, and have obtained the authentication of CCC, CE, FCC and UL ISO9001, etc. So far, our products have been well marketed in 107 countries and regions in the world. Our company has set up research and development centers, including GPS R & D department, GSM R & D department and system integration Department. All the products are developed independtly and obtained a number of national patents. So the professional R D team, efficient production team provide good foundation with high-quality products. Quality has always been part of the company's most stressed. Before all the products entering the market, they have been tested rigorously such as high and low temperature aging test, vibration test, the noise tests, audio and video indicators decomposition tests.
Our company specialized in GPS tracker, car anti-theft alarm system.
Except the advantage of abundant in human resources, since we count on long standing business relationships, we deserves wide range of cooperation with the well-known Chinese and foreign high-tech companies and service in the long term. In order to meet the developing of the markt, our aim is to transform the latest and the best research fruit into productive quickly, develope science and technology, serve the society.
