Green PVC Insulation CCA Conductor Electrical Cable

Prod Model:	YC
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color:	Orange, Black, Green etc
Voltage:	>360V
Conductor:	Copper,Copper Clad Aluminum,Tinned Copper
Insulation:	PVC,NBR
Cores:	1
Temperature:	-15~70 C
Rate Voltage:	100/100V
Type:	Insulated
Conductor Type:	Stranded
Conductor Material:	Copper
Insulation Material:	PVC
Application:	Welding Machine
Range Of Application:	Power Transmission
Brand:	Huahao

Product Description

SPECIFICATION
high quality flexile welding cables are suitable for dry and wet Indoor and outdoor usage.

1.Specific property for using
 16mm2 25mm2 35mm2 50mm2 70mm2 95mm2 120mm2
  0AWG-20AWG

 1.1. The cable can be used in the connectors of electric weld and pliers of the electrical welding
whose toward earth voltage of the low voltage is not more than AC 200V and the pulsating DC peak value is 400V.
 1.2. The long term permissible working temperature of cable conductive core is not more than 65°C.

  Applicant:



Application
           Leading wire for welding machine and also applied to power or electrical household appliances and a variety of mobile or electrical devices and tools with AC rated voltages of Uo / U 450/750V and below.
           This welding cable is used to power the secondary circuit of electric welding generators,the circuit that controls the electrode that emits the charge used to weld.While welding cable is not meant to be part of any other system,It has a history of being used for public lighting arrangements.

Construction
Conductor : Flexible Bare annealed copper wire or Tinned Copper wire
Insulation: Nitrile-Butadiene-PVC  or PVC
Sheath: Nitrile-Butadiene-PVC or PVC

Choice of Black, Orange, Red or Yellow Blue jacket, single & double insulated.
SQ MM sizes (European style) 10 sq mm to 240 sq mm
AWG sizes (North American style) 6 Awg to 500 MCM
With sequential foot / meter marking
Wide temperature range: -15°C to 90°C
