GS 90W 90mm AC Induction Motor

Name: GS 90W 90mm AC Induction Motor
Brand: all-electronics-online.com
SKU: 743136165
Availability: InStock
Rating: 4.9 (46 reviews)

Price:	US $ 43.5-46/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	100/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	GS51K90GU-AF/5IK90GU-CF
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Mid East,Eastern Asia
Power:	90W
Voltage:	220~230V/110V
Frequency:	50/60Hz
Rated Torque:	450mm.M
Number Of Stator:	Single-Phase
Function:	Control
Certification:	UL\CE\RoHS
Brand:	GS

Product Description

Introduction
Generally, Micro Induction Motor refers to the motor rotated by the induction. Induction Motor relies on capacitor and electromagnetism when starting and rotating. Though its starting torque is not very high, it has a simple structure, high efficiency and can rotate continue.

About Greensky Power
History:Greensky Power Co.,ltd was founded in Los Angeles in 2008 and has focused on manufacturing and supplying the renewable products and components for 8 years since 2008.
Market:Greensky Power has customers in 30 different countries.Germany, Austria, Japan, USA and Middle-East are our main market.
Honors:Greensky Power is member of a council in Zhejiang Solar Association which is the biggest renewable energy association in Southeast of China.

Model		Output power W	Voltage V	Frequency Hz	Current A	Starting Torque mN.m	Rated Torque mN.m	Rated Speed r/min	Capacitor μF
Lead Wire Type	Terminal Box Type
5IK90GU-AF (5IK90A-AF)	5IK90GU-AFT (5IK90A-AFT)	90	1ph100	50	1.55	450	700	1250	25.0
				60	1.85		570	1550
5IK90GU-EF (5IK90A-EF)	5IK90GU-EFT (5IK90A-EFT)	90	1ph110	60	1.40	500	570	1550	20.0
			1ph120		1.45
5IK90GU-CF (5IK90A-CF)	5IK90GU-CFT (5IK90A-CFT)	90	1ph220	50	0.72	450	700	1250	5.0
			1ph230		0.70
5IK90GU-HF (5IK90A-HF)	5IK90GU-HFT (5IK90A-HFT)	90	1ph220	60	0.71	450	570	1550
			1ph230		0.75
5IK90GU-SF (5IK90A-SF)	5IK90GU-SFT (5IK90A-SHT)	90	3ph220	50	0.60	1350	700	1250	_
				60	0.55	1100	570	1550
