GS High Efficient 15W 60mm DC Gear Motor

Name: GS High Efficient 15W 60mm DC Gear Motor
Brand: all-electronics-online.com
SKU: 743527985
Availability: InStock
Rating: 4.7 (120 reviews)

Price:	US $ 20-24.9/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	2D15-24/2DW15-24
Markets:	North America,South America,Africa,Eastern Asia,Western Europe
Speed:	3000rpm
Power:	15W
Voltage:	12V/24V/90V
Rated Torque:	48mn.M
Current:	1A
Brush Life:	2000h
Structure And Working Principle:	Brush
Operating Speed:	High Speed
Application:	Power Tools
Excitation Mode:	Excited
Brand:	GS
Certification:	CCC, CE, UL, Cu

Product Description

Introduction
Brushless dc motor (bldc) is made up of motor and driver, which is a kind of typical product of mechanical and electrical and electrical integration. It is high regarded by market as its small volume, low noise, high efficiency, wide range of speed control and steady working state with less inaccuracy.

Specifications
1. Dimensions of device: Dia 60mm
2. Rated Power: 15W
3. Voltage: 24/36/48V
4. CCC, CE, UL, CU
5. Can be customized

Greensky's advantage
On the site you can find a range of renewable products including ac/dc motor, ac induction motor, reversible motor, blake motor, speed motor, ac angel motor, gear motor, planetary gear box, worm gear box and their relevant components.

If you have any other questions, please feel free to contact us.

Model	Voltage V	Rated Power W	No-load Parameters		Load Parameters			Brush Life H	Motor Weight kg
Model	Voltage V	Rated Power W	Speed RPM	Current A	Speed r/min	Torque mN.m	Current A	Brush Life H	Motor Weight kg
2D15-12	12	15	3200	0.8 Max	2950	48	2.0	2000	0.9
2DW15-12	12	15	3200	0.8 Max	2950	48	2.0	2000	0.9
2D15-24	24	15	3300	0.4 Max	3000	48	1.0	2000	0.9
2DW15-24	24	15	3300	0.4 Max	3000	48	1.0	2000	0.9
2D15-90	90	15	3200	0.2 Max	3000	48	0.4	2000	0.9
2DW15-90	90	15	3200	0.2 Max	3000	48	0.4	2000	0.9

About Greensky Mechanical

History: Greensky Mechanical was founded in 2012 with purchasing of a 15 year old cooperative factory in Zhejiang Province. Greensky Power brought new management concept to the new joint company and increase the quality of the motors as Greensky Power only provides best quality and best service to the society.

Introduce: Greensky Mechanical Co., Ltd is a subsidiary company of Greensky Power which is producing AC and DC gear motor, gearbox and motor, and it has capability to design and develop customized product with high quality.

Philosophy: We save cost by increasing the efficiency of production and delivery. "Once and forever" is our goal to serve customers in the world. Once we do business with customer, we will do business forever.

GS motor makes the cool mechanism human by progress in thchnology and products innovation. GS bases on talents. Products are the morality of man. Wisdom and passion of us are the core power. GS

Motor has made her own stronger through the long-term experience and exerise. GS believes that we raise ourself continuously in future. GS will go on innovating forever.
