GSM Wireless Terminal/GSM Wireless Gateway Etross-8818 (1 SIM Card Supported)

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color:	White
Fwt Weight:	800g
Connection Mode:	Rj-11 Phone Socket
Size:	L185 X W135 X H22mm
Cetificate:	CE
Warranty:	1 Year
Type1:	Wireless
Usage:	Telephone
Support Network:	Switch
Type:	Wireless

Product Description

Brand: ETROSS or OEM brand
Model No.: ETROSS-8818G
Product name: GSM FWT Fixed Wireless Terminal(1 SIM Card Supported)
Frequencies: GSM 900/1800MHz

General:
Etross-8818G GSM is a Fixed Wireless Terminal designed to provide better wireless connectivity between POTS (plain old telephone set) and existing GSM 900/1800MHz network with high sensitivity to receive signal and large transmitting power to expand extensively the effective coverage of GSM service. It can be used not only in communication for vehicles such as automobiles, trains, floating vehicles, etc., but also in communication for construction sites, isolated islands and rural areas where hardwire-line telephone service is unavailable. So they are widely used in home &office, public phone, rural areas, steamer, railway etc.
Etross 8818G FWT---a solution for expanding GSM service coverage!

Features and Functions:
1) Caller ID display
2) Own ID hides(optional)
3) As a GSM gateway (FCT)
4) Imei changeable(optional)
5) Back-up battery(optional)
6) Lock PIN/network(optional)
7) No noise and clear voice
8) As a fixed line replacement
9) Support DTMF 2'ND dialing out
10) Strong signal with high gain antenna
11) Simple to install and easy to maintain
12) Can provide reversal polarity signal for metering
13) Comptiable to any telephone, PBX, VoIP, quintun, arterisk
14) Connects to Alarm system to realise wireless alarm (for security use)

Specifications:
1) Air interface standard: GSM 900 / 1, 800MHz phase 2+
2) Frequency ranges:
A) GSM 900:
I) Transmission: 890 ~ 915MHz
Ii) Reception: 935 ~ 960MHz
B) GSM 1800:
I) Transmission: 1, 710 ~ 1, 785MHz
Ii) Reception: 1, 805 ~ 1, 880MHz
3) Channel space: 200KHz
4) User line, bell signal: In line with GB/T15279
5) Max power: 0.25W / 0.5W
6) Consumption:
A) Immobility: < 25mAh
B) Transmission: < 400mAh
7) Sensitivity: -105dB
8) Dial tone frequency: 450MHz (standard)
9) Antenna amplification: 3.5dB (omni-direction), 12dB (certain direction/chosen direction)
10) AC power: DC 10V - 20V
11) Input: AC100 - 230V, 50 / 60Hz
12) Output: 12V 1A
13) Switch type / transform type AC adapter (optional)
14) Connector of power: China
15) Connection mode: RJ-11 phone socket
16) Antenna connection: SMA antenna connection
Operation circumstance
1) Operation temperature: -10° C ~ +40° C
2) Operation humidity: 45% ~ 90% (without frost)
3) Atmosphere pressure: 86 ~ 106KPa
4) Environment noise: <60dB

Packaging:
1) Dimension(L x W x H) (average): 185 x 135 x 22mm
2) Weight:
A) FWT: 400g
B) Total weight: 850g
3) Color: White / blue (optional)
