(GW5-110) Outdoor Disconnect Switch (Composite Insulator Type)

Name: (GW5-110) Outdoor Disconnect Switch (Composite Insulator Type)
Brand: all-electronics-online.com
SKU: 677813455
Availability: InStock
Rating: 4.3 (27 reviews)

Price:	Negotiable/Set
Trade Terms:	FOB,CFR,CIF
Min Order:	50/Set
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	GW5-110
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Outdoor Installation:	Three Phase
Type:	High-voltage
Structure:	Three-column Disconnector
Installation:	Outdoor High-voltage
Operation:	Manual
Grounding:	Single Ground
Series:	Single-Stage
Run:	Turn the Horizontal
Switching Mode:	Double-Throw Type
Common Model:	Gn6

Product Description

Outdoor Disconnect Switch Model GW1-12/36 (Composite Insulator Type)
GW1-12(36)/630-20(25) Outdoor HV Disconnect Switch is used to open and close circuit with voltage but no0load 50/60Hz, 12(36)KV power system. The anti-pollution type can be used in the serious pollution area. Three pole linkage, good synchronous performance.

Note: For detail, please refer to the catalogue.

No.	Item	Unit	Data
1	Rated volatge	kV	12,36
2	Rated current	A	630
3	Rated power frequency	Hz	50/60
4	Rated peak withstand current	kA	50,63
5	Rated short-time withstand current	kA	20,25
6	Rated short-time withstand current duration	S	4
7	Main loop resistance	μΩ	12kV≤90,36kV≤100
8	1min(dry) power frequency withstand voltage	kV	42/48 ,95/115
9	1min(wet) power frequency withstand voltage	kV	30 ,85
10	Lightning impulse withstand voltage(peak)	kV	75/85 , 185/215
11	Mechanical life	Times	2000

Haivo Electrical Co., Ltd, is a provider of power equipment and services for the global electric utility industry. It mainly manufacture power transmission & distribution equipments, covering many product series as Fuse cutout, Surge arrester, Composite & Porcelain insulator, Disconnector switch & Load Break Switch, Hardware fitting for overhead line, Cable accessories and Cable kits (cold & heat shrinkable cable accessories).

HAIVO ELECTRICAL, As one of the international electrical companies in China, We not only manufacture the power equipment, but also provide sustainable power solutions underpinned by technology innovation. To date, HAIVO conducts business in nearly 50 countries and territories in South America, Europe, Latin America, Asia, Africa, and the Middle East. HAIVO′ S high standards have received due recognition from the local power customers.

HAIVO′ S worldwide operation and sales coverage is backed by exceptional experience and expertise to provide customers with the most reliable and highest quality products and services available.

For the quality control system, HAIVO was successively awarded ISO 9001: 2008 by DAS CERTIFICATION Ltd & UKAS QUALITY MANAGEMENT, and TYPE TEST REPORT by China NATIONAL HIGH VOLTAGE APPARATUS QUALITY SUPERVISION TESTING CENTER(XIHARI) & QUALITY INSPECITION AND TEST CENTER FOR EQUIPMENT OF ELECTRIC POWER.

We promise we will offer first-class quality, reasonable price, first-class service and following the business philosophy of development and innovation to serve global power customers!
