Gyfxty Indoor/Outdoor Optical Fiber Cable

Name: Gyfxty Indoor/Outdoor Optical Fiber Cable
Brand: all-electronics-online.com
SKU: 688288252
Availability: InStock
Rating: 4.6 (109 reviews)

Price:	US $ 0.11-0.15km
Trade Terms:	FOB,CFR,EXW
Min Order:	2000km
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	GYFXTY
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Loose Tube:	PBT
Jacket Material:	LSZH
Fiber:	Sm
Strength Member:	Glass Yarn
Application:	Sensor
Type:	Single-mode Fiber
Certification:	CE
Connection Structure:	GYFXTY
Brand:	OEM or Geyida

Product Description

GYFXTY Indoor/outdoor Optical Fiber Cable:

1. Good mechanical and temperature performance.
2 Heigh strength loose tube that is hydrolysis resistand
3. Specially tube filling compound ensure a critical protection of fiber.
4. Crush resistance and rlesxibility
5. Two parallel FRO ensure tensile strength
6. Small diameter, light weight and frecndly installation.

GYFXTY Indoor/outdoor Optical Fiber Cable:

1. Good mechanical and temperature performance.
2 Heigh strength loose tube that is hydrolysis resistand
3. Specially tube filling compound ensure a critical protection of fiber.
4. Crush resistance and rlesxibility
5. Two parallel FRO ensure tensile strength
6. Small diameter, light weight and frecndly installation.

Options:
Fiber Type:G.652, G.655 or 6.657 single-mode fiber. A1a or A1b, OM3 or OM4 mufti-mode fiber, or other types of fiber;
Jacket Material: Environmental flame retardant polyvinylchloride(PVC), environmental low smoke zero halogen flame retardant palyolefin(LSZH),environmental halogen flame retardant polyolefin(ZRPO), environmental thermasplatic polyurethane(TPU), or other contracted material;
Jacket Color:(Including color of tiber) meets the requirements of relevant standards, or other contracted color;
Cable Dimension: The nominal cable dimension, or other contracted dimension;
Delivery Length: 1 km or 2km, or other contracted length;
Other Requirements: Other contracted special requests.

optical characteristics



		G.652	G.655	50/125um	62.5/125um
attenuation(+20ºC)	@850nm			≤3.0db/km	≤3.0db/km
	@1300nm			≤1.0db/km	≤1.0db/km
	@1310nm	≤0.36db/km	≤0.4db/km
	@1550nm	≤0.22db/km	≤0.23db/km
	@850nm			≤600mhz.km	≤200mhz.km
bandwidth(class A)	@1300nm			≥1200mhz.km	≥600mhz.km
numerical Aperture				0.200±0.015na	0.275±0.015na
cable cut-off waveleng th xcc				≤1620nm	≤1450nm
storage/operating temperature:-40ºC to +70ºC
storage/operating temperature:-40ºC to +70ºC
