Hangzhou DAYTAI Network Technologies Co., Ltd. >> Heat Resitance Jca CATV Qr412 Coaxial Cable

Heat Resitance Jca CATV Qr412 Coaxial Cable

Heat Resitance Jca CATV Qr412 Coaxial Cable
Price: US $ 0.1-20/Meter
Trade Terms: FOB,CFR,CIF
Min Order: 20000/Meter
Pay Type: L/C,T/T,D/P,Paypal,Western Union
Prod Model: QR412 Coaxial Cable
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name: Jcam Qr320 Coaxial Cable
Number Of Conductors: 1
Coverage: 40%~95% Al Wire
Jacket: PE
Conductor: CCA/Bc
Messenger: No
Out Conductor Material: Al
Dielectric Material: Foam PE
Application: Telecommunication
Cover Material: PE
Certification: UL
Model: Qr412 Coaxial Cable
Brand: Daytai

Product Description

Heat Resitance JCA CATV QR412 Coaxial Cable

Costruction of QR412 CATV Coaxial Cable:

QR412 CATV Coaxial Cable , CCA+Foam PE+ Al TUBE+ PE.PACKING:1KM/Wood Spool.

Specification of QR412 CATV Coaxial Cable :

1.Application:CATV,CCTV,DBS
2.Conductor.Dia.:2.26mm
3.Conductor Material:CCA/BC
4. Dielectric Material :Foam PE
5. Dielectric Dia. :9.19MM
6.Out Conductor material:Al
7.Jacket:PE
8. CE,UL,ROHS standard
9.MOQ:20 kms
10. OEM service
11.Sample is available

Application of QR412 CATV Coaxial Cable :

1.CATV-community antenna television
2.DBS-direct broadcasting satellite
3.CCTV-closed-circuit television

Basic Construction of QR412 CATV Coaxial Cable


  412
CONDUCTORMATERIALCCA/BC
NOm.Dia.2.26mm
DIELECTRICMATERIALFoam PE
NOm.Dia.9.19mm
OUT CONDUCTORMATERIALAL
NOm.Thick.0.25mm/0.6mm
NOm.Dia.9.8mm
Nom.Dia.over Flooded Jacket/
JACKETMATERIALPE
NOm.Thick.1.05mm
NOm.Dia.12.07mm
MESSENGERNOm.Dia./
Nom.Shield Thickness/
