Heavy Copper Double Sided PCB Multilayer PCB Heater Control Power PCBA Board

Name: Heavy Copper Double Sided PCB Multilayer PCB Heater Control Power PCBA Board
Brand: all-electronics-online.com
SKU: 764962585
Availability: InStock
Rating: 4.9 (39 reviews)

Price:	US $ 0.12-0.21/Piece
Trade Terms:	FOB,EXW
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	Fl9915
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Board Thickness:	1.6mm
Copper Thickness:	1oz
Material Type:	Fr4
Surface Treatment:	HASL Lead Free
Solder Mask:	Green, Red, Blue, Black
Silk Screen Color:	White
Board Layer:	2 Layer
Shipping Type:	DHL, UPS, TNT, EMS, FedEx etc
Packing Type:	Carton + Vacumm
Lead Time:	5-7 Days
Type:	Rigid Circuit Board
Dielectric:	FR-4
Material:	Fiberglass Epoxy
Flame Retardant Properties:	V1
Base Material:	Fr4
Brand:	Fastline

Product Description

Product Description

Heavy Copper Double Sided PCB Multilayer PCB Heater Control Power PCBA Board

This is a type of FR-4 PCB for the application of Switching Power Supply. It's a 2 layer board at
3.2mm thick. The base laminate is from ITEQ, Solder mask and silkscreen from Kuangshun and
Taiyo. It's fabricated per IPC 6012 Class 2 using supplied Gerber data. Each 10 boards or panels
are packed separately.

Parameters & Data Sheet

PCB SIZE	79 x 32mm=1PCS
BOARD TYPE
Number of Layers	Double sided PCB, 2 Layer PCB
Surface Mount Components	NO
Through Hole Components	YES
LAYER STACKUP	copper ------- 216um(6oz)+plate TOP layer
	FR-4 2.8mm
	copper ------- 216um(6oz)+plate BOT Layer
TECHNOLOGY
Minimum Trace and Space:	14 mil/29 mil
Minimum / Maximum Holes:	0.55/15.0mm
Number of Different Holes:	12
Number of Drill Holes:	431
Number of Milled Slots:	0
Number of Internal Cutouts:	0
Impedance Control	no
BOARD MATERIAL
Glass Epoxy:	FR-4, ITEQ IT-140 TG>135, er<5.4
Final foil external:	6oz
Final foil internal:	0oz
Final height of PCB:	3.2mm ±0.32
PLATING AND COATING
Surface Finish	Hot air soldering leveling(HASL), lead free, Sn>=2.54µm
Solder Mask Apply To:	Top and Bottom, 12micron Minimum
Solder Mask Color:	Blue, KSM-6189BL04, Kuangshun supplied
Solder Mask Type:	LPSM
CONTOUR/CUTTING	Routing
MARKING
Side of Component Legend	TOP
Colour of Component Legend	White, IJR-4000 MW300, Taiyo Supplied.
Manufacturer Name or Logo:	Marked on the board in a conductor and leged FREE AREA
VIA	Plated Through Hole(PTH)
FLAMIBILITY RATING	UL 94-V0 Approval MIN.
DIMENSION TOLERANCE
Outline dimension:	0.0059" (0.15mm)
Board plating:	0.0030" (0.076mm)
Drill tolerance:	0.002" (0.05mm)
TEST	100% Electrical Test prior shipment
APPLICATION:	Power Inverters Switching Power Supply Solar Inverter Invertor Grid Tie Inverter Tattoo Power Supply
TYPE OF ARTWORK TO BE SUPPLIED	email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA	Worldwide, Globally.

Why choose us

PCB Capability

Workshop

Ship&package

Fastline is a Leading PCB manufacturer in China. It was found in 2003, serving customers in over 40 countries from various electronic industries, Over 70% of products are exported to America, Europe and other Asia Pacific countries.

Fastline could meet all your PCB manufacturing needs, including High multilayer PCB, Aluminum based PCB, HDI PCB, Rigid-flex PCB, heavy copper PCB, and PCB assembly as well. Our products are widely applied in telecom, industrial control, power electronics, medical instrument, security electronics, aerospace and so on.

And provides "PCB One-stop PCB solution" to meet customers' diverse demands.

Our factories with a facility area of more than 40, 000 square meters with 1000 professional staff, And we have got the approval of ISO9001 certificates. ULCertification and all Products Meet RoHS compliance.

Fastline Circuits is commited to provide superior quality products and services that consistently meet and exceed our customers requirements on time, every time!
