| Prod Model: |
underground mining cable |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Voltage: |
600-25kv |
| Cross Section: |
1.5,2.5,4.0,6.0,10,16,25,35,50,70,95mm2 |
| Sheathed Color: |
Red Black Yellow |
| Price: |
Direct Factory Price |
| Certificate: |
UL Ce TUV BV Kema SABS ISO |
| Products Name: |
Mining Cable |
| Cable Type: |
Underground |
| Oil Resistance: |
Yes |
| Type: |
Insulated |
| Conductor Type: |
Stranded |
| Application: |
Mining |
| Conductor Material: |
Copper |
| Insulation Material: |
Rubber |
| Sheath Material: |
Rubber |
| Brand: |
Rneda |
Product Description
Hebei Huatong Group hot selling Underground Mining Cable with UL Certificate
Product Description 1)Brief introduction1 Rated voltage of the cables is divided into 6 grades, which is 0.3/0.5kV,0.38/.066kV,1.9/3.3kV,3.6/6kV,6/10kV.
2 There are allowed long-term working temperatures of the cable conductor. For the cable of U(M)CPT-0.66/1.14, U(M)CPJB-0.66/1.14, U(M)CPJR-0.66/1.14 and 1.9/3.3kV, 3.6/6kV, 6/10kV, the temperature is 90ºC;for the other, it is 65ºC.
3 Minimum bending radius: For the cable of U (M)CPJB-0.66/1.14, U(M)CPJR-0.66/1.14,it is 15 times of the cable diameter; for the others, it is 6 times of the cable diameters.
4 The grounding wire should be well connected with the earth.
5The cable should be prevented from exposing to the sunshine for a long time.
2)Implemented standard 1For the non-spread combustion cable, implement GB12972
2For the flame-retardant cable, implement MT818
3 For the special mining cable(with bigger cross-section and higher voltage),implement the enterprise standard.
3) Type and Name:
Type |
Description |
Application |
MC-0.38/0.66 |
Rubber flexible cable for excavator |
As the power connection used in the excavator
or similar equipment with rated voltage 0.38/0.66kV |
MCP-0.38/0.66 |
Shielded, rubber-sheathed flexible cable for excavator |
As the power connection used in the excavator
or similar equipment with rated voltage 0.38/0.66kV |
MCP-0.66/1.14 |
Shielded, rubber flexible cable for excavator |
As the power connection used in the excavator
or similar equipment with rated voltage 0.38/0.66kV |
MCPJB-0.66/1.14 |
Shielded ,monitoring and braiding reinforced type,
rubber flexible cable for excavator |
As the power connection used in the excavator
or similar equipment with rated voltage 0.66/1.14kV,
it can be dragged directly |
MCPJR-0.66/1.14 |
Shielded ,monitoring and braiding reinforced type,
rubber flexible cable for excavator |
As the power connection used in the excavator
or similar equipment with rated voltage 0.66/1.14kV,
it must be used in the protective chain panel |
MCPT-0.66/1.14 |
Metallic shielded rubber flexible cable for excavator |
As the power connection used in the excavator
or similar equipment with rated voltage 0.66/1.14kV |
MCP-1.9/3.3 |
Shielded rubber flexible cable for excavator |
As the power connection used in the excavator
or similar equipment with rated voltage 1.9/3.3kV |
MCPT-1.9/3.3 |
Metallic shielded rubber flexible cable for excavator |
As the power connection used in the excavator
or similar equipment with rated voltage 1.9/3.3kV |
MCPTJ-1.9/3.3 |
Metallic shielded, monitoring type, rubber flexible cable for
excavator |
As the power connection used in the excavator
or similar equipment with rated voltage 1.9/3.3kV |
MY-0.38/0.66 |
Movable rubber flexible cable for mining |
As the power connection used in the mining
machine with rated voltage 1.9/3.3kV |
MYP-0.38/0.66 |
Movable shield rubber flexible cable for mining |
As the power connection used in the mining
machine with rated voltage 0.38/0.66kV |
MYP-0.66/1.14 |
Movable shield rubber flexible cable for mining |
As the power connection used in the mining
machine with rated voltage 0.66/1.14kV |
MYPJ-3.6/6 |
Monitoring movable shield rubber flexible cable for mining |
As the power connection used in the mining t
ransformer and similar equipment with rated voltage3.6/6kV |
MYPTJ-3.6/6 |
Metallic shielded monitoring type movable
rubber flexible cable |
As the power connection used in the mining
transformer and similar equipment with rated voltage3.6/6kV |
MYP-3.6/6 |
Movable shield rubber flexible cable for mining |
Mining equipment with rated voltage 3.6/6kV
the min. environment temperature is-20ºC |
MYPT-3.6/6 |
Movable metallic shield rubber flexible cable for mining |
Mining equipment with rated voltage 3.6/6kV
the min. environment temperature is-20ºC |
MYPD-3.6/6 |
Movable shield rubber flexible cable for mining |
Mining equipment with rated voltage 3.6/6kV
the min. environment temperature is-40ºC |
MYPTD-3.6/6 |
Movable metallic shield rubber flexible cable for mining |
Mining equipment with rated voltage 3.6/6kV
the min. environment temperature is-40ºC |
MZ-0.3/0.5 |
Driller cable for mining |
As the power connection of driller with rated
voltage 0.3/0.5kV |
MZP-0.3/0.5 |
Driller shielded cable for mining |
As the power connection of driller with rated
voltage 0.3/0.5kV |
MYQ-0.3/0.5 |
Movable light-type rubber flexible cable for mining |
Lighting in the mine, as the power connection
of the interlock and control signals
used in the transport machine and equipment |
Company Information
HeBei huatong wires&cables Group Co.,ltd.It was established in 1993, we are JV with Furukawa(Japanese company) for rubber serious cables and JV with Riken(Japanese company) for elevator cables. Besides these,our submersible oil pump cable and shipboard cable are very influential in domestic, and, the traditional cables are also produced such as PVC power cables, XLPE power cables, ABC cables, wires, control cables, screened cables,communication cables, conductors.We are OEM for many USA, Europen, Australia cable company, 70% of our products are exported, most customers are from developed countries. We got ISO,UL,TUV,KEMA,CE and many other certifications.
FAQ
(1).When can I get the price?We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please
call us or tell us in your e-mail so that we will regard your inquiry priority.
(2).How can I get a sample to check your quality?After price confirmation, you can require for samples to check our quality. Sample is free, but the freight
charge should be paid.
(3).How long can I expect to get the sample?After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7
days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account orprepay us if you do not have an account.
(4).What about the lead time for mass production?Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
Established in 1993, Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220, 000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billion Chinese Yuan. Now there are more than 800 employers in our company, among which more than 150 are technicians. With the continuous efforts from all the employers, Hebei Huatong Wires and Cables Group Co., Ltd has realized great development to become a modern enterprise and one of the comprehensive, large-scale enterprises in domestic wire and cable industry. Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects. We are JV with Furukawa(Japanese company) for rubber serial cable (minding cables, welding cables. Submersible oil pump cables, . )and also JV with Riken(Japanese company) for elevator cables. Our products have extensive influence and good reputation in both domestic and worldwide market, such as the United States, Holland, Italy, Russia, Britain, Australia, New Zealand, Ethiopia, Ghana, Algeria, South Africa, Congo, Middle East and Southeast Asia countries and so on.
