Prod Model:	QD-S2
Capacity:	10~60t
Digital Module Resolutions:	100000
Accuracy:	0.02%Fs
Compensate Temperature:	-10~60ºC
Defend Grade:	IP68
Accessories:	Yes
Product Name:	High Accuracy Digital Sensor and Analog Sensor

Product Description

High Accuracy Digital Sensor and Analog Sensor Applications QD-S2
Features:

Alloy steel or stainless material, stable and reliable performance
Easy installation and debugging , good interchangeability
Measuring range: 10t~60t

4. Double spherical surface reset automatically to the core part, select modules to install, it can resist side-force effectively. Reliable sealing, long-term stability
5. Application in the weighing system like motor truck scale etc.
Technical Specifications:

Rated load	t	10,20,30,40,60
Digital module resolution	Code	100000
Accuracy	%FS	±0.02
Linearity error	%FS	±0.02
Hysteresis error	%FS	±0.02
Repeatability error	%FS	±0.01
Creep error	%FS/30min	±0.02
Influence of temp. on zero	%FS/10ºC	±0.02
Influence of temp. on sensitivity	%FS/10ºC	±0.02
Transmission distance	m	RS232≤30m;RS485≤1000m
Baud rate	BPS	600/1200/2400/4800/9600
Zero output	%FS	±0.1
Safe load	%FS	150
Excitation voltage	V	9~12(DC)
Compensated temp.	ºC	-10~+60
Operating temp.	ºC	-20~+60
Defend grade	IP	IP68

Accessories:

Packaging & Shipping

Standard exporting package: each unit has individual box and packed in paper box. Waterproof protect.
According to the clients requirement

Our Services

We are committed to providing a high quality,and responsive services to all clients
Detailed informations, specific and price of products will be provided quickly after receiving your inquiry.
Quality assurance: All products will be make sure the quality in a year, and replace new product with any quality problems. All products will be checked by our quality-control and enclose with testing data.
Packageing: well box packed and provide optimal freight for you refrence.
All products OEM available

Company Information

Han Zhong Quan Yuan Electronic Co., LTD. is a professional high-tech enterprises committed to the research, development, design and manufacture and sale of load cell, high precision resistance strain gauge, sensor, fittings for electronic weighing apparatus and automatic control system with QuanYuan brand.
