High Accuracy Truck Scale Weighing Axle Load Cell (B715)
| Price: |
US $ 18-20/Piece |
| Min Order: |
2/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal,Money Gram |
| Prod Model: |
B715 |
| Capacity: |
10-25,40-50se,50-75klb 100-125,200klb |
| Custom: |
Size and Accuracy Could Be Customed |
| Pattern: |
Single Point |
| Out-Wire: |
5 Wires |
| Feature: |
High Precision |
| Production Process: |
Strain Gauge |
| Material: |
Aluminum |
Product Description
1. Name:5.6,13.5T high accuracy steel Double ended shear beam Load Cells
2. Material: Stainless steel or alloy steel
3. Capacity:5.6, 13.5T4. Accuracy: C3
l Made of stainless steel.
l High accuracy, high side load tolerance
l Easy to install, IP65 protection
l Mainly used for electronic scales, truck scale and industrial weighing systems
5. Datasheet| Number | Specifications | /Technique |
| 1 | Capacity | 5.6,13.5T |
| 2 | Accuracy class | C3 |
| 3 | Rated output | 0.50±0.005mV/V |
| 4 | Zero balance | ±2.00%F.S. |
| 5 | Non-linearity | ±0.1%F.S. |
| 6 | Hysteresis | ±0.1%F.S. |
| 7 | Repeatability | ±0.1%F.S. |
| 8 | Creep(30min) | ±0.1%F.S. |
| 9 | Temp.effect on output | 0.02%F.S./10ºC |
| 10 | Temp.effect on zero | 0.02%F.S./10ºC |
| 11 | Input impedance | 385±10Ω |
| 12 | Output impedance | 350±3Ω |
| 13 | Insulation | ≥5000MΩ/100VDC |
| 14 | Recommended excitation | 10V |
| 15 | Maximum excitation | 15V |
| 16 | Compensated temp range | -10~50ºC |
| 17 | Operation temp range | -20~60ºC |
| 18 | Safe overload | 120%F.S. |
| 19 | Ultimate overload | 200%F.S. |
| 20 | Cable size | Φ6×12000mm |
| 21 | Material | Stainlss Steel |
| 22 | IP Class | IP68 |
6. Instruction
Double Ended Shear Beam Load Cell is constructed from high grade tool steel for resistance to heavy shock loads associated with truck weighing. It is electroless nickel plated for corossion resistance.
A high accuracy load cell/mounting accessory combination for large silo, tank, hopper or vessel weighing. It is an excellent solution for most high capacity applications, whether in harsh wash-down environments or hazardous areaswhere there is a risk of explosion. It also used for agriculture, forestry,measuring the weight of gardage truck's wheel and axle; portable truck scales and other industrialweighing systems
The double shear beam load cell is manufactured from high strength stainless steel or alloy steel and available in capacities from 10,000kg to 50,000kg. Formore than 20 years, it has been known worldwide as a leading load cell for high capacity weighing, thanks in part to its fully welded and hermetically sealed design, giving protection to IP68.
Key Features:
This cell is designed to load from center through ball cup mechanism which helps for self restoring and self centering for improvement in accuracy.
It is offered with full mounting assembly for easy installation.
Trusted design for more than 20 years
Resistant to off-axis loading
Low profile design with substantial lift-off protection
Capacity range 5.6,13.5T
Fully welded and hermetically sealed stainless steel load cell, protected to IP68/IP69K
Need something special or a completely customized design? Contact BRANS to discuss your particular application requirements. www.bransensor.com
What you could get from Brans?
Load Cells, Miniature and sub-miniature force sensors, Pressure Transducers/sensors, Torque Transducers, Temperature sesensors, Flow senesors, Displacement Transducers (LVDTs), Digital Gauges, Strain Gauges, Instrumentation for Test, amplifiers and data acquisition systems as well as software for structural durability investigations, tests and analysis, Measurement and Other Applications.
Why choose Brans?
Brans cooperate with HBM, FLINTEC, METTLER TOLEDO, Honeywell, Vishay and other famous brand electronic measuring instruments and system. We could learn and get the most advanced technology and news of procedures. Good manufactures means good products.
We could OEM for miniature and sub-miniature load cells with tension or compression; Big capacity load cells/sensors Brans also could make it with good quality material.
Brans products (load cells, force sensors, amplifiers… ) have been certified per ISO9001, OIML, CE, RoHS, NETP AND ATEX. Brans could promise you the best quality for measuring products.
Who Brans cooperate with?
Brans have developed solutions for a wide range of industries including automotive, aerospace, military and defense, oil and gas, R&D and material/test labs, machine and automation equipment designers and builders, off highway and heavy equipment manufacturers, medical device manufacturers, semiconduct or fabricators, utilities and energy companies, marine equipments and shipbuilding.
