High Current DC-DC Solid State Relay

Name: High Current DC-DC Solid State Relay
Brand: all-electronics-online.com
SKU: 765993745
Availability: InStock
Rating: 4.9 (135 reviews)

Price:	US $ 10/Piece
Trade Terms:	FOB
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

Application :

High rellability by S.M.T & TQC.(Surface Mounting Technology)
High Isolation over than 50MQ/500VDC
High dielectric over than 2.5KV
Low enable current less than 7.5mA/12VDC CMOSIC or TTL Compatible.
Low EMI/EFI& surge by Zeero cross Trigger Method.
High surge current duration,over 10 Times of rated current/one cycle.
High surge voltage duration by snubber circuit.

Guiding of Model :

Control Method :

Zero Cross Trigger Method
Output TURN ON or TURN OFF only on zero cross point of sine wave,may avoid surge or EMI/RFI occurring.
Specially suited to control resistive,capacitive and Non-saturated inductive loads

Variable resistance control method
Power output is controlled by the trigger angle of triac with variable resister 250KQ/110VAC,500KQ/220VAC

Application Hints :

Input	NPN	Output	NO	Input	NPN	Output	NO	Input	NPN	Output	NO

Input	NPN	Output	NO	Input	NPN	Output	NO	Input	NPN	Output	NO

Type	Standard type			PCB type
Model	PN-10DD	PN-25DD	PN-40DD	PN-05DD
Rated load current	10A	25A	40A	5A
Input voltage	3-32VDC
Min. on/off voltage	ON>2.4V, OFF<1.0V
Trigger current	7.5mA/12V
Control method	Isolated by photocouple
Operating voltage	5-110VDC			5-110VDC
Min. black voltage	500VDC
Voltage drop	1.0V/25ºC
Max. durated current	30A	75A	120A	30A
Leakage current	≤ 0.8mA
Response time	1ms
Dielectric strength	Over 2.5KVAC/ 1min.
Isolation strength	Over 50M/500VDC
Operating temperature	-20ºC~+80ºC
Housing Material	Intensive ABS
Weight	105G
