Product Description
High Density Swaged Cartridge Heater
General Information
Superb Heater Technology manufactures custom made watlow cartridge heaters for any application. Electric cartridge heaters are a versatile and economical heat source for a wide variety of industrial and commercial applications.
Standard tube diameters are 6mm, 8mm, 10mm, 12mm and 16mm, but other special sizes are available for cartridge heater too. Depending on the diameter, lengths can be supplied up to 6000mm. Standard sheath materials are Stainless Steel 201, 304, 316 and 321, but special sheath materials may be available based on diameter and size of the element required.
Electric cartridge heater provide superior heat transfer, uniform temperatures, resistance to oxidation and corrosion and long life even at high temperatures. Flexible lead wire extensions or other mounting options are available for specific applications.
Characteristics & Properties
- Tube diameter: Φ6mm-Φ30mm
- Tube Material: SS201, SS304, SS316, SS321 and INCOLOY800 etc
- Insulation Material: MgO
- Conductor Material: Nichrome Resistance Wire
- Wattage Density: High/Middle/Low (5-25w/cm2)
- Lead Connection Option: Threaded Stud Terminal or Lead Wire
- Lead Wire Type: 300mm Standard (Teflon/Silicone High Temperature Fiberglass are available for watlow cartridge heater)
Heat intensity | Not exceeding 30w/cm2 (advisable) |
Power | Depends on the dimension |
Exhaust extreme (when cold) | <=0.1mA to 242 v. |
Insulation (when cold) | 5 Min Ohms 500 Watts minimum |
Dielectric strength | 1500v. 1/sec |
Working temperature | 650 Deg C max. |
Length tolerance | +/-1.5% |
Diameter tolerance | -0.02 to -0.06 mm |
Cut off connection tolerance | +/-15 mm |
Power tolerance (w) | +5 % - 10 % |
Cold areas | Depends on length and diameter 5-25mm |
Suggested Applications
- Semiconductor Chamber Heating
- Semiconductor Wafer Lead Connection
- Semiconductor Wire and Die Bonding
- Freeze Protection and Deicing of Equipment in Cold Climates or Applications
- Humidity Control
- Patient Comfort Heating used in Medical Devices
- Mold Die and Platen Heating
- Seal Bars used in Packaging Equipment
- Test Sample Heating in Gas Chromatography
- Heat Transfer Machine
To Order
For this type cartridge heater, outside diameter and length are available on request.
Please contact us with your special requirements. We are pleased to contact you if you would like more information or want to discuss custom heater elements availability and pricing.
Welcome to order sample high density swaged cartridge heater for initial evaluation.
| OUR ADVANTAGES |
| 1. | Minimum order: 5pcs |
| 2. | Delivery time : in stock 1-2days ,out stock 3-7days |
| 3. | More than 50 different sizes stock |
| 4. | Provide OEM service |
| 5. | Quality Assurance:Under normal conditions consistent with the design range 365days |
