| Prod Model: |
LGH/TCC |
| Environmental Certification: |
ISO14001 |
| Quality Certification: |
ISO9001 |
| Other Certification: |
RoHS |
| Safety Certification: |
CQC03003095~3097 |
| Tolerance: |
5%,10% |
| Type: |
Choke Inductor |
| Structure: |
Inductive Choke |
| Brand: |
Liwang |
Product Description
| Model | inductor coil |
| Operation frequency | 8KHz-1MHz |
| Output power | 0.05 to 3000 W |
| Working temperature | -40ºC to +200ºC |
| Storage temperature | -25ºC to +85ºC |
| Storage humidity | 30 to 95% |
| Remark | The popular bobbin style is shown as the above.
Other special styles are not listed. Our company can make iron silicon
and aluminum magnetic coils with different specifications and size according
to client's requirement.Welcome to inquire. |
| Application | Iron,silicon and aluminum magnetic coil is applied to alternative transformers,
output inductors,line filters and PFC circuit.
Sometimes it is used as a transformer core to substitute the air gap ferrite. |
| Price | Its unit price is from USD1.0 to 10/pcs FOB Shanghai
. The price depends on technical complexity, clients' requirement for material and safety certificates. |
ferrite core toroidal inductor
| Toroidal Inductor Transformer Series |
| Model :OR8-OR102(inductance coil color:green, gray, red, yellow and white) |
| No. | Model | Outer diameter(mm) | inside diameter(mm) | High(mm) |
| 1 | OR8x5x3 | 8.0 | 5.0 | 3.0 |
| 2 | OR10x6x5 | 10.0 | 6.0 | 5.0 |
| 9 | OR12x6x4 | 12.0 | 6.0 | 4.0 |
| 11 | OR13x6x7 | 13.0 | 6.0 | 7.0 |
| 12 | OR13x7x5 | 13.0 | 7.0 | 5.0 |
| 13 | OR14x8x7 | 14.0 | 8.0 | 7.0 |
| 16 | OR16x8x5 | 16.0 | 8.0 | 5.0 |
| 17 | OR16x9x5 | 16.0 | 9.0 | 5.0 |
| 21 | OR18x10x10 | 18.0 | 10.0 | 10.0 |
| 23 | OR19x13x11 | 19.0 | 13.0 | 11.0 |
| 26 | OR20x12x10 | 20.0 | 12.0 | 10.0 |
| 27 | OR22x14x8 | 22.0 | 14.0 | 8.0 |
| 31 | OR25x15x12 | 25.0 | 15.0 | 12.0 |
| 36 | OR28x18x13 | 28.0 | 18.0 | 13.0 |
| 38 | Or29x19x15 | 29.0 | 19.0 | 15.0 |
| 39 | OR31x18x14 | 31.0 | 18.0 | 14.0 |
| 40 | OR31x19x13 | 31 | 19 | 13 |
| 44 | OR36x23x15 | 36 | 23 | 15 |
| 46 | OR38x19x13 | 38 | 19 | 13 |
| 47 | OR38x19x15 | 38 | 19 | 15 |
| 52 | OR40x23x20 | 40 | 23 | 20 |
| 53 | OR40x25x20 | 40 | 25 | 20 |
| 54 | OR42x26x18 | 42 | 26 | 18 |
| 55 | OR45x30x15 | 45 | 30 | 15 |
| 56 | OR47x27x15 | 47 | 27 | 15 |
| 57 | OR48x30x10 | 48 | 30 | 10 |
| 58 | OR48x30x15 | 48 | 30 | 15 |
| 60 | OR49x31x19 | 49 | 31 | 19 |
| 62 | OR50x25x20 | 50 | 25 | 20 |
| 63 | OR51x31x13 | 51 | 31 | 13 |
| 64 | OR56x32x18 | 56 | 32 | 18 |
| 66 | OR58x40x18 | 58 | 40 | 18 |
| 67 | OR60x38x20 | 60 | 38 | 20 |
| 70 | OR63x38x25 | 63 | 38 | 12.7 |
| 71 | OR68x44x15 | 68 | 44 | 15 |
| 72 | OR74x40x13 | 74 | 40 | 13 |
| 73 | OR80x50x20 | 80 | 50 | 20 |
| 74 | OR87x54x14 | 87 | 54 | 14 |
| 75 | OR87x54x30 | 87 | 54 | 30 |
| 76 | OR100x50x20 | 100 | 50 | 20 |
| 77 | OR102x66x15 | 102 | 66 | 15 |
Specifications
| Item Name | ISO Factory Good Price UL ROHS CQC Certified 1H Ferrite Toroidal Core Adjustable Coils Inductor |
| Model No. | CH-TC6826 |
| Components | Ferrite core, Copper wire;Basing;Shielding case |
| Core | NiZn/Iron /MnZn/MPP/Amorphous magnetic |
| Wire | Enameled copper wire-UEW/PEW |
| Functions | Power line filter/Signal line filter/Energy saving/Voltage step-up etc/Choke etc |
| Mounting type | Surface mount ;Through hole ; Wire lead |
| Shape Types | Vertical;Horizontal;with/without base;shielded/unshielded ;SMD |
| Coil Structure | Toroidal |
| Working Frequency Range | 1KHZ-100MHZ |
| Inductance Range | 1uH-1H |
| DCR Range | unknown-Depend on customers' request |
| Storage Temperature | -20ºC to +85ºC |
| Working Temperature | -20ºC to +105ºC |
| Storage Humidity | 30% to 95% |
| Test Items | Ø Turns Ratio
Ø Inductance
Ø DC resistance test
Ø Safety test
Ø Current test
Ø Hi-POT |
| Certifications | ISO9001:2008, ISO14001:2008, |
| MOQ | 1000 pcs |
| OEM | Acceptable |
| Sample | Free |
| Sample Time | 3-5 working days |
| Package | EPE foam + export carton, or plastic tray+export carton |
| Delivery time | about 15 days against deposit |
| Feature | 5 years warranty
High current High power High efficiency
Low temperature rise
Stable performance |
| Applications | 1. VCRS, Copy machine , Audio equipment , Game machines
2. TV sets, Microcomputer equipment, printers, Terminals
3. communications control equipment
4.Switching power supply, chargers, alarm system
5. UPS, VCD/DVD players, audio and visual equipment
6. OA machines, inverters, chargers, alarm system |
FAQ:
Q1.Is it the sample free of charge?
A: Small sample is for free, but the freight shoulb be undertook by customer.
Q2.What is the delivery time.
A:About 7-15 days, if small sample, we will send to you ASAP.
Q3.Can you accept OEM&ODM products?
A:Yes,we could offer OEM & ODM products.
Q4.What are your main products in your company?
A: Induction cooker,infrared cooker, electronic accessories, all kinds components in circuit board.
Q5.What are the best hot selling products recently?
A: Induction,transformer,choke coil,resistor.
